AE3400 IIoT controller
16
A: For a permanent connection between the device and the USB connector:
ATTENTION
“Hot plugging” at the USB port of the device is not permitted.
w Destruction of the USB interface or the externally connected USB device possible.
u Only connect the USB connection cable to a USB port when the device is switched off.
u Use a prewired cable (art. no. EC2099 or EC9125, M12 connector, B-coded on USB socket,
type A, waterproof, cable length 1.5 m, wires twisted and screened).
u Insert the connector of the USB connection cable into a free USB port of the device.
u Tighten the cable plug using 1.3 ± 0.1Nm.
B: For temporary connection between USB connector and USB device:
“Hot plugging” is permitted at the USB port (type A) of the USB connector of the connected M12
adapter.
u Connect the USB memory device to the connector of the connection cable.
u Use a connection cable labelled “Full Speed/High Speed”.
u Do not use more than one USB cable for the connection.
After use:
u Remove USB memory device and connection cable for temporary connection.
6.6 Functional earth
The FE potential is connected to the following points of the device:
• FE connection
u To avoid contact corrosion on the FE connection of the housing, do not use any copper or
nickel-plated materials for the bolting elements!
u To ensure the protection of the device against electrical interference as well as its intended
function and safe operation, connect the housing using the shortest possible route.
Mobile applications / on-board system:
u Connect the FE connection of the device to the body or GND of the supply.
Industrial applications:
u Connect the FE connection of the device to the earth of the system or GND of the supply.
u Use an M4 screw to make the connection.
• Max. tightening torque: 2.5 ±0.5 Nm
• Usable thread depth in the device: 7mm
6.7 Voltage supply
The device is connected to the supply voltage via the PWR port.
The port has reverse polarity protection.
Wiring:
