Part 1 – Introduction
12
Bottom Panel
1 2
345
1
Joystick Bracket
2
Factory Reset Switch
3
Joystick Input Port
4
RS485 NVR Termination (1)
5
RS485 PTZ Termination (2)
1 Joystick Bracket
Use the provided bracket and screws to attach the
joystick to the network keyboard body. The joystick
can be attached to either the left or right of the
network keyboard body.
2 Factory Reset Switch
Returns all settings to the factory defaults. For more
information, see Factory Reset.
3 Joystick Input Port
Connect the cable from the joystick. The joystick
cable must be connected while the network
keyboard is o.
4 RS485 NVR Termination (1)
RS485 NVR Termination (1) switch is not supported.
5 RS485 PTZ Termination (2)
Set the switch ON if RS485 communication
environment is not normal and the connection is
not made while controlling a PTZ camera via RS485
connection.
Do NOT connect or disconnect the joystick cable while
the network keyboard is on. The network keyboard
must be turned o while connecting or disconnecting
the joystick cable; otherwise, it may aect the network
keyboard or cause it to malfunction.
Factory Reset
When performing Factory Reset, the settings you have
saved are lost.
You can perform Factory Reset while the network
keyboard is on. Poke a straightened paperclip into the
factory reset switch hole and hold the switch for about
three seconds. After releasing the switch, the factory
reset function is performed. The function also can be
performed remotely using the IDIS Discovery program.
The network keyboard restarts after nishing the
function. Refer to IDIS Discovery Operation Manual on
the installation CD provided with the network keyboard.
For more details about remote factory reset.
