ITEM TYPE DESCRIPTION
7 Device 1 LED
LED is SOLID ON when routing is made to Device 1.
LED will display BLUE, YELLOW, GREEN, or RED depending on if the routing is made
to Host A, B, C, or D respectively.
LED is OFF if not routing to Device 1.
8 Device 2 LED
LED is SOLID ON when routing is made to Device 2.
LED will display BLUE, YELLOW, GREEN, or RED depending on if the routing is made
to Host A, B, C, or D respectively.
LED is OFF if not routing to Device 2.
9 Device 3 LED
LED is SOLID ON when routing is made to Device 3.
LED will display BLUE, YELLOW, GREEN, or RED depending on if the routing is made
to Host A, B, C, or D respectively.
LED is OFF if not routing to Device 3.
10 Device 4 LED
LED is SOLID ON when routing is made to Device 4.
LED will display BLUE, YELLOW, GREEN, or RED depending on if the routing is made
to Host A, B, C, or D respectively.
LED is OFF if not routing to Device 4.
11
Reset/Test
Button
Factory Reset and Test mode button. Refer to page 8 for more details.
See Testing Function section on page 8 for more detail.
See Factory Reset section on page 8 for more detail.
12 DC Power IN Locking connector for the included 24V 2.71A power adapter.
13
Network
Interface
100Mbps interface for internal webpage and network (SSH, TELNET) APIs.
Connect to a network for network-based control.
14 RS232 Interface Congurable baud rate RS232 interface for control with APIs.
15 Device 4 Port
USB-C Port supporting up to USB 3 5Gbps.
15W of power available 5V 3A. Supports USB data only.
16 Device 3 Port
USB-C Port supporting up to USB 3 5Gbps.
15W of power available 5V 3A. Supports USB data only.
17 Device 2 Port
LED BLINKS when the system is updating USB-A Port supporting up to USB 3 5Gbps.
6W of power available 5V 1.2A.
18 Device 1 Port
USB-A Port supporting up to USB 3 5Gbps.
6W of power available 5V 1.2A.
6
