1
BEFORE USING THE CONTROLLER
1-3
Panel description
■ Front panel
9<UPDATE> BUTTON ��� When [MSG] lights green, a firmware update is ready. Hold down this
button until [MSG] blinks green to update the firmware.
L Use a pin to push the button.
<INIT> BUTTON ����� Push to initialize the settings. See Section 3 for details.
L Use a pin to push the button.
<USB EJECT> BUTTON � When removing the USB flash drive, hold down this button until
[USB] (4) turns OFF.
[USB] PORT
(USB 3.0) �������� Connect a USB flash drive (user supplied) to save or restore settings or
to update the firmware.
L You can save the recorded audio on a data storage device through the USB
port. Only one storage device can be connected to the USB port at a time.
L Be sure to back up the data on the USB ash drive before connecting it to
the Controller.
L A USB ash drive, such as one with biometric authentication, or one with
password protection is not supported.
L Some USB devices may not be usable with the IP1100CV.
[CONSOLE] PORT
(USB Type-C) ������ Connect a USB (Type-C) cable (user supplied) to remotely configure
the Controller from a PC using a terminal software (user supplied.)
About the USB driver
To use the [CONSOLE] port, the USB driver for the Icom network
devices is required.
Download the USB driver from the Icom website and install it on your
PC.
https://www.icomjapan.com/support/
1 8 9 234567
