4
REPEATER AND DUPLEX OPERATION
4-4
Duplex operation
The duplex operation shifts the transmit frequency
up or down from the receive frequency by an oset
amount�
D Setting the frequency oset
1� Push [SET] to enter the Set mode�
• A Set mode item is displayed�
2� Repeatedly push [SET] to select “OFFSEt�”
3� Rotate [DIAL] to set the frequency offset�
• “DUP” blinks�
L Set to between 0�000 and 20�000 (MHz)�
L Changes in the tuning step selected in the Set mode�
4� Push [V/M/C] to exit the Set mode�
UHF default
VHF default
D Setting the duplex direction
1� Push [SET] to enter the Set mode�
• A Set mode item is displayed�
2� Repeatedly push [SET] to select “dUP�”
3� Rotate [DIAL] to set a duplex direction�
• OFF: The receive and transmit frequencies are the
same�
• –: The transmit frequency shifts down from the
receive frequency by the oset amount.
• +: The transmit frequency shifts up from the
receive frequency by the oset amount.
4� Push [V/M/C] to exit the Set mode�
• “DUP” or “DUP-” is displayed when the duplex
direction is set�
–
+
D Duplex operation
1� Hold down [MONI] to listen to the transmit
frequency to check whether another station is
transmitting on it or not�
• The frequency shifts by the oset amount.
2� Operate in the same way as a simplex call,
alternately transmit and receive�
NOTE for the USA version:
The Duplex mode is automatically canceled
when the Auto Repeater function (p� 4-5) is
ON, and the operating frequency is set out of the
repeater output frequency range�
