TABLE OF CONTENTS
IMPORTANT .............................................................. i
EXPLICIT DEFINITIONS ............................................ i
FEATURES ................................................................ i
PRECAUTIONS ..........................................................ii
SAFETY TRAINING INFORMATION ........................iii
FCC INFORMATION .................................................iii
PRÉCAUTIONS .........................................................iv
INFORMATION SUR
LA FORMATION À LA SÉCURITÉ ............................ v
INFORMATION FCC ................................................. v
SUPPLIED ACCESSORIES ......................................vi
OPTIONS ..................................................................vi
1. PANEL DESCRIPTION ........................................ 1
■
Front panel ........................................................ 1
D
Function display ............................................ 2
■
Rear panel ........................................................ 2
D
Accessory connector .................................... 3
2. INSTALLATION AND CONNECTIONS ............... 4
■
Unpacking ......................................................... 4
■
Selecting a location ........................................... 4
■
Antenna connection .......................................... 4
■
Power supply connection .................................. 4
■
Replacing fuse .................................................. 4
D
Line fuse replacement .................................. 4
■
Mounting the repeater ....................................... 4
D
Using the supplied handles ........................... 4
■
Front panel connection ..................................... 5
■
Rear panel connection ...................................... 5
■
Installing the Channel extension module .......... 6
D
Opening Case ............................................... 6
D
Installation .................................................... 6
D
Assemble the unit ......................................... 7
3. OPERATION ......................................................... 8
■
Receiving and transmitting ............................... 8
D
Repeater operation ....................................... 8
D
Base station operation .................................. 8
4. MAINTENANCE ................................................... 9
■
Troubleshooting ................................................ 9
5. INFORMATION ................................................... 10
■
About CE and DOC ........................................ 10
■
About UKCA DOC .......................................... 10
■
Disposal .......................................................... 10
■
Voice coding technology ................................. 10
■
Installation notes ............................................. 11
SUPPLIED ACCESSORIES
The following accessories are supplied.
Handles For handle attachment
Spacers
Screws
DC power cable
(OPC-1784)
DC power cable for
cooling fan (CAB-1149)
OPTIONS
• SP-35 external speaker
Compact and easy-to-install.
Input impedance: 4 ø
Rated input: 5 W
Maximum input: 7 W
• HM-152 hand microphone
• SM-26 desktop microphone
• UR-FR5300/UR-FR6300
channel extension modules
• UC-FR5300 trunking/network controller
Some options may not be available in some
countries. Please ask your dealer for details.
