4
9
MAINTENANCE
■
Troubleshooting
The following chart is designed to help you correct
problems that are not equipment malfunctions.
If you are unable to locate the cause of a problem
or solve it through the use of this chart, contact your
nearest Icom Dealer or Service Center.
PROBLEM POSSIBLE CAUSE SOLUTION REF.
Power does not
come on when
[POWER] is pushed.
• DC power cable is improperly connected.
• Fuse is blown.
• Correctly reconnect the DC power cable.
• Find the cause and repair it, then replace
the fuse with a rated one.
pp. 4,
5
p. 4
No sound comes
from the speaker.
• The volume level is too low.
• The squelch is closed.
• The audio mute function is activated.
• A selective call or squelch function is
activated, such as 5-Tone call or tone
squelch.
• The front speaker is set to OFF.
• Rotate [VOLUME] clockwise to obtain a
suitable listening level.
• While in the base operating mode, rotate
[SELECT] to counterclockwise to open
the squelch. (When the [SQL Level Up/
Down] key function is assigned to [SE-
LECT].)
• Push [MONI] (if assigned) to turn the
audio mute function OFF.
• Turn OFF the appropriate function.
• Turn ON the front speaker using the op-
tional programming software CS-FR5300.
Ask your dealer for details.
p. 8
p. 8
–
–
–
Sensitivity is low, and
only strong signals
are audible.
• Antenna feedline or the antenna con-
nector has a poor connection or short-
circuited.
• Check and reconnect (or replace if neces-
sary), the antenna feedline or antenna
connector.
p. 5
Output power is too
low.
• Output power is set to Low.
• The power amplier protecttor circuit is
activated.
• Push [HIGH/LOW] (if assigned) to select
High power.
• Cool down the repeater or stop accessing
the repeater until it has cooled down.
–
–
No contact possible
with another station.
• The other station is using signaling
squelch.
• The operation mode is set to the Full-
duplex mode. (Base station operation)
• Turn the signaling squelch function ON.
• Set the operation mode to the Simplex
mode, if the other station is in the Simplex
mode.
–
–
