3
8
OPERATION
■ Receiving and transmitting
D Repeater operation
Ask your dealer for details of the repeater’s preset-
tings.
zz zWhen the repeater is ON, the [PWR] indicator
lights green. (p. 1)
zz zThe [TX] or [BUSY] indicator lights simultaneously
while transmitting/receiving a signal.
• The [TX] indicator lights red.
• The [BUSY] indicator lights green.
NOTE: The repeater has a built-in power amplier
protector. A protector circuit is activated when the
repeater temperature becomes exceptionally high,
due to long periods of transmitting, to reduce the
transmit output power level. The output power will
return to its normal level when the repeater has
cooled down.
D Base station operation
Receiving
1. Push [POWER] to turn ON the power.
2. Set the audio and squelch levels.
z Rotate [SELECT]*
1
fully counterclockwise in
advance.
z Rotate [VOLUME] to adjust the audio output
level.
z Rotate [SELECT]*
1
clockwise until the noise
just disappears.
3. Push [CH Up]*
2
or [CH Down]*
2
to select the
desired channel.
• When receiving a signal, the [BUSY] indicator lights
green, and audio is heard from the speaker.
• Further adjustment of [VOLUME] to a comfortable
listening level may be necessary at this point.
*
1
When the [SQL Level Up/Down] key function is assigned
to [SELECT].
*
2
When the [CH Up]/[CH Down] key functions are as-
signed.
Transmitting
1. Take the microphone off the hook.
2. Wait for the channel to become open.
3. Hold down [PTT] to transmit, then speak into the
microphone at your normal voice level.
4. Release [PTT] to receive.
IMPORTANT:
To maximize the audio quality of the transmitted
signal:
1. Pause briey after pushing [PTT].
2. Hold the microphone 5 to 10 cm (2 to 4 inch)
from your mouth, then speak at your normal
voice level.
