4-10
BASIC MANUAL
4
RECEIVING AND TRANSMITTING
Split frequency operation
Split frequency operation enables you to transmit and
receive on dierent frequencies on the Main and the
Sub bands.
There are 2 ways to use Split frequency operation.
• Use the Quick Split function.
• Use the receive and transmit frequencies set to the
Main and Sub bands.
The other station Your station
Transmit frequency
USB mode
21.29000 MHz
Main band
Receive frequency
Receive frequency
USB mode
21.29500 MHz
Sub band
Transmit frequency
3. Rotate
MAIN
DIAL
to set the Sub band’s transmit
frequency.
(Example: 21.29500 MHz in the USB mode)
D Using the Quick Split function
The Quick Split function enables you to automatically
equalize the frequency and mode of the Main band to
the Sub band, and activate the Split function.
1. Set the Main band’s receive frequency and
operating mode.
(Example: 21.29000 MHz in the USB mode)
2. Hold down
SPLIT
for 1 second.
• The Quick Split function is turned ON, and the Main
band settings are set to Sub band.
Displayed
D Using the receive and transmit
frequencies set to Main and Sub bands
1. Set the Main band’s receive frequency and
operating mode.
(Example: 21.29000 MHz in the USB mode)
2. Touch the Sub band’s frequency readout to select
the Sub band, and then set the receive frequency
and the operating mode.
(Example: 21.29500 MHz in the USB mode)
3. Push
SPLIT
.
L Pushing
SPLIT
turns the Split function ON or OFF.
4. Touch the Main band’s frequency readout to
return to receive on the Main band.
L The Split frequency operation is ready.
Displayed
TIP: You can select whether or not to display the
F-INP screen when turning ON the Quick Split
function.
MENU
»
SET > Function > SPLIT >
Display Keypad on Quick SPLIT
