3-10
BASIC MANUAL
BASIC OPERATION
3
3
Adjusting the transmit output
power
Before transmitting, monitor your selected
operating frequency to make sure you do not cause
interference to other stations on the same frequency.
It is good amateur practice to listen rst, and then,
even if nothing is heard, ask if the frequency is in
use once or twice, before you start operating.
1. Select the operating mode. (p. 3-4)
(Example: RTTY)
2. Touch the meter, and then touch [Po] to display
the Po meter. (p. 3-11)
Transmit Power Limit function
The Transmit Power Limit function limits the output
power to the preset level for each band.
1. Open the TX POWER LIMIT screen.
MENU
»
SET > Function > TX Power Limit
2. Touch the desired band to limit the output power.
(Example: 3.5M)
3. Touch [+] or [–] to set the maximum transmit
output power. (Example: 50 W)
4. Touch to save the maximum transmit output
power.
• Returns to the previous screen.
5. To close the TX POWER LIMIT screen, push
EXIT
several times.
Set transmit output power
Limited transmit output power
L Even when set RF POWER
exceeds the TX POWER LIMIT
setting, the actual output power is
limited to this value.
3. Push
MULTI
to open the Multi-function menu.
4. Hold down [PTT] on the microphone.
• The TX/RX indicator lights red, and is displayed.
• The Po meter level changes according to your voice
level in the SSB mode. It becomes the S-meter while
receiving.
5. Touch [RF POWER], and rotate
MULTI
to adjust
the transmit output power between 2 W and
200 W, or “< 2 W.”
L In the AM mode, the maximum transmit output power
is a quarter of the other mode’s output.
L The transmit output power is limited to the maximum
transmit output power.
6. Release [PTT].
• Returns to receive.
Po meter
