1-8
BASIC MANUAL
PANEL DESCRIPTION
1
1
Touch screen display (Main screen)
D Multi-function menus
z Open the Multi-function menu by pushing
MULTI
(Multi-function control).
L You can open other menus by holding down
NB
,
NR
,
NOTCH
,
APF/TPF
, or
VOX/BK-IN
for 1 second,
or touching key on the FUNCTION screen.
z While the Multi-function menu is open, touch the
desired item and rotate
MULTI
to set the desired
value.
Multi-function menu items
*
1
Touch the item for 1 second to adjust by rotating
MULTI
,
even when the Multi-function menu is closed.
*
2
Touch the edge to turn the function ON or OFF, or to
adjust the selected item.
SSB SSB-D CW RTTY/PSK
RF POWER*
1
RF POWER*
1
RF POWER*
1
RF POWER*
1
MIC GAIN*
1
MIC GAIN*
1
KEY SPEED*
1
COMP*
1
*
2
CW PITCH*
1
DIGI-SEL*
1
*
2
DIGI-SEL*
1
*
2
DIGI-SEL*
1
*
2
DIGI-SEL*
1
*
2
MONITOR*
1
*
2
MONITOR*
1
*
2
SIDETONE
*
1
MONITOR*
1
*
2
AM/AM-D FM/FM-D NB NR
RF POWER*
1
RF POWER*
1
LEVEL*
1
LEVEL*
1
MIC GAIN*
1
MIC GAIN*
1
DEPTH*
1
DIGI-SEL*
1
*
2
DIGI-SEL*
1
*
2
WIDTH*
1
MONITOR*
1
*
2
MONITOR*
1
*
2
NOTCH APF ATT VOX
POSITION*
1
POSITION
*
1
LEVEL*
1
GAIN*
1
WIDTH*
2
WIDTH*
2
ANTI VOX*
1
TYPE*
2
DELAY*
1
AF LEVEL*
1
VOICE DELAY*
2
BK-IN
DELAY*
1
Touch the edge to
turn ON or OFF
D Multi-function key group
z Touch a key to turn the function ON or OFF.
z Touching “ATT,” “DIGI-SEL,” or “COMP” for 1
second opens the Multi-function menu.
z Touching “AGC” or “TONE” for 1 second opens the
AGC or TONE menu.
Multi-function key group items
SSB SSB-D
CW/
RTTY/
PSK
AM/
AM-D
FM/
FM-D
ANT
✓ ✓ ✓ ✓ ✓
P.AMP
✓ ✓ ✓ ✓ ✓
ATT
✓ ✓ ✓ ✓ ✓
DIGI-SEL
✓ ✓ ✓ ✓ ✓
IP+
✓ ✓ ✓ ✓ ✓
AGC
✓ ✓ ✓ ✓ ✓
COMP
✓
1/4
✓ ✓
TONE
✓
Touch the edge to
turn ON or OFF
Multi-function menu Multi-function key group
