MANUAL - SCAN Laser Systems
5
www.ibiza-light.com
EN
OVERVIEW OF PLAYBACK MODES:
There are multiple playback modes:
• Built-in Master mode: divided into three small playback modes.
>1: mixed playback: Drawing scenes from each sequence in taking turn playback (can be set by setting the
function).
>2: Sequence playback: only play a sequence. (This mode for the temporary mode, restart laser will not
automatically enter)
>3: Scene playback: only play a scene. This mode for the temporary mode, restart laser will not automati
-
cally enter)
• Slave mode: divided into the following two slave modes:
>1: DMX slave mode: Through the DMX signal line to follow the Master to play.
>2: ILDA slave mode: Accept the ILDA signal control from the Master or laser console.
• DMX playback mode:
>1: Easy DMX mode: 5 channels
Note: Simple DMX mode takes the built-in scenes of the laser directly without any further settings.
CHANNEL DMX value DESCRIPTION
CH 1
On/o power
0 OFF
1-255 ON
CH2
Act auto/sound
0-127 AUTO
128-255 SOUND CONTROLLED
CH3
Gallery Menu
(scenes)
0-15 1 gallery (0)
16-31 2 gallery (16)
32-239 3 gallery (32)
240-255 40 gallery (240)
CH4
Scenes
0-255 Each value corresponds to a pattern, the value exceeds the number of pat-
terns, the system with the largest number instead
CH5
Colors
0-31 RGB
32-63 red
64-95 yellow
96-127 green
128-159 blueviolet
160-191 blue
191-223 purple
224-255 white
>2: Professional DMX mode: 34 channels
Order 1: Professional DMX mode is available to the experienced lighting engineers, who are pro
-
fessional in DMX control, as well as the laser pattern scanning principle , if not, pls use simple DMX
mode 4 channels
Order 2: DQF6 (the Bluetooth number) is a double-pattern laser system, and two patterns can be
scanned at the same time. The following description is distinguished by pattern A and pattern B.
For ease of view, the following points are shown in Table 1 and Table 2 respectively at the end of
the manual.
