REMOTE CONTROL

ON/OFF button

MODE: Press until the desired operating mode is displayed

MUTE: Sound stop

▶ǁ Play/pause: Press to play a track, press to pause. In FM mode: Search for radio

stations

REC: Press to start, stop and play a recorded 󰊟le

/CH-: back to the previous track. In FM mode: back to the previous radio station

/CH+: Go to the next track. In FM mode: Go to the next radio station

RPT: Repeat one/repeat all tracks

TWS: Press to switch the unit into TWS pairing mode to connect to a 2nd PORT-

VHF-MKII-TWS box

VOL-: Reduce the volume

Vol+: Increase the volume

EQ: Select among several sound modes (Rock, Pop, Jazz, Classic, Flat)

TRK: Track selection. Press the TRK button, select a track via the number keys (0-

9) and press ENTER to con󰊟rm

Number buttons: Press the number of the desired track

ENTER: Once you have made your selection, press ENTER to con󰊟rm.

CARE

Before cleaning the unit, disconnect it from the mains. Do not use aggressive cleaning agents. Use a clean cloth

to wipe any dust or dirt from the product. We are not liable for damage arising from incorrect handling, impro-

per use or wear and tear. We reserve the right to make technical changes.

SPECIFICATIONS

Woofer ..................................................................................................................................................................8"/20cm

Tweeter ................................................................................................................................ 1"/25mm compression driver

Sensitivity ........................................................................................................................................................ 96dB±2dB

Impedance .............................................................................................................................................................4 Ohms

Freq. range ...................................................................................................................................................60Hz - 20kHz

Built-in battery ..................................................................................................................................3 x 3.7V󰐆 2500mh

Bluetooth frequency .................................................................................................................................. 2402-2480MHz

Max. BT RF power ................................................................................................................................................1.50dBm

VHF handheld mic freq. ......................................................................................................................................207.5MHz

Mic Hand max. RF power ..................................................................................................................................... 7.67dBm

Power supply .................................................................................................................................................13.5V󰐆 3.5

Consumption ..............................................................................................................................................................45W

Dimensions ........................................................................................................................................ 290 x 230 x 430mm

Weight ...................................................................................................................................................................... 6.5kg

RECOMMENDATIONS FOR BATTERIES

This symbol indicates that used batteries should not be disposed of with household waste but deposited in separate

collection points for recycling.

ATTENTION: Danger of explosion if battery is incorrectly placed. Only replace by the same or equivalent type.

WARNING

Do not swallow the battery. Danger of chemical burns. The supplied remote control contains a button cell. In case of inges-

tion, it might cause serious internal burns within only 2 hours that might lead to death.

Keep new and old batteries out of the reach of children.

If the battery compartment doesn't close properly, stop using the product and keep it out of the reach of children.

If you are in doubt whether the batteries have been swallowed or introduced into any other part of the body, contact im-

mediately a doctor.
