17. Short press: Backward/Forward; Long press: VOL-/VOL+

18. Master volume control

19. VOX control activated/deactivated

20. Treble & Bass control

21. Battery Volume and Charge LED

22. Power ON (green) and Battery low (red) LED

23. Power Switch

24. 13.5V󰐆 3.5 power supply input

25. VHF function ON/OFF switch. Press to ON prior to using the VHF microphone

PLAY MP3/WMA MUSIC

26. Switch on power (23). The LED indicator (22) lights up in green.

27. Insert a USB stick (1) or an SD card (13) into the relevant input

28. Select a title via the  or  buttons and press ▶ǁ (16)

TO PLAY LINE IN MUSIC

1. Insert an RCA plug into the LINE IN sockets (8)

2. Insert a wired microphone into MIC INPUT (9)

3. Adjust the MIC VOL (5)

VOX FUNCTION

When VOX function is enabled, the music level will decrease when somebody talks into one of the microphones.

The music level becomes normal when the user stops talking into the microphone.

To activate this function, switch the VCV switch (19) to on. If you want to disable this function, set this switch to

o󰊞 position

REC FUNCTION

Disconnect the speakerbox from your Bluetooth device. Insert a USB stick or SD card. The speaker will automa-

tically switch into USB/SD mode. Connect now the speakerbox to your Bluetooth device and start playing your

music. Short press the REC button to record your voice and the music on the inserted USB stick or SD card.

Press again to stop recording. Keep the REC button pressed to play the recorded 󰊟le.

BLUETOOTH FUNCTION

1. Switch on your Bluetooth device and activate the Bluetooth connect function

2. Select IBIZA-PORT in the list of found devices and connect.

3. Press the MODE switch to BT function,

4. Now you can play Bluetooth music.

TWS FUNCTION)

This function allows to pair 2 units of the PORT-VHF-MKII-TWS range with 1 single Bluetooth source to enjoy

wireless stereo sound.

Turn o󰊞 the Bluetooth feature on your smartphone. Switch on both speakers and select BT-UDIO mode on both.

Keep the TWS button on one of the speakers (master speaker) pressed for a few seconds. If the connection was

successful, you will hear the message “left channel” from the master speaker, and “right channel” from the

slave speaker. Activate the Bluetooth function of your smartphone and select IBIZA-PORT in the list of found

devices. Now the master speaker is connected to your Bluetooth source. After that, you can use any mode to

play music in TWS mode.

HOW TO USE THE VHF MIC

Press the VHF ON/OFF button (25) to activate the VHF function. Turn on the VHF microphone using the switch on

the microphone body. Adjust the volume using the VHF volume control (6).
