3 Before the journey
32 Exsis I/T - 01/23-1 - EHG-0027-02EN
Fig. 4 Lock (rear ladder)
◼ Insert the key into the locking cylinder (Fig. 4,2) of the rear ladder lock
(Fig. 4,1) and turn it a quarter turn until the key is in a vertical position.
◼ Hold the foldable part of the rear ladder (Fig. 4,4) and swing out the se-
curing bracket (Fig. 4,5).
◼ Pull out the key and fold the rear ladder downwards.
◼ Fold the rear ladder upwards and hold it firmly.
◼ Insert the key into the locking cylinder (Fig. 4,2) of the rear ladder lock
(Fig. 4,1).
◼ Swivel the securing bracket (Fig. 4,5) inward around the tube of the
fixed part of the rear ladder (Fig. 4,3).
◼ Turn the key a quarter turn until it is in a horizontal position.
◼ Check the rear ladder lock: Slightly pull on the rear ladder.
3.2.5 Rear garage / rear storage space
Observe the technically permissible maximum mass on the axle and
the technically permissible maximum laden mass when loading the
rear garage / rear storage space.
The maximum permitted load of the rear garage/the rear storage
space is 350 kg. If the vehicle is fitted with a caravan coupling or a
motorcycle rack, the permitted load is 450 kg. Do not exceed the tech-
nically permissible maximum mass on the rear axle.
Uneven loading or overloading has a negative effect on driving behav-
ior. A rear-heavy load in particular results in a reduction of the load on
the front axle due to leverage effects and thus, for example, to a loss
of traction, a diminished steering response (altered driving behavior),
an overloading of the tires and, as a result, an increased risk of tire
blowouts. This may cause you to lose control of the vehicle, endan-
gering yourself and other road users. An evenly distributed load over
the entire vehicle leads to optimum driving behavior during travel. If
you are not sure whether the loaded vehicle complies with the techni-
cally permissible maximum laden mass and the technically permissi-
ble maximum laden mass on the axle, you can weigh/check the vehi-
cle on public scales or have it weighed by certain dealers.
Do not exceed the maximum permissible external load on the rear
wall/rear flap. Only equipment components approved by the manufac-
turer are permitted (e.g. certain bike racks).
Rear ladder
Folding downwards:
Folding upwards:
