10 Sanitary fittings
172 Exsis I/T - 01/23-1 - EHG-0027-02EN
Fig. 148 Flap (sewage tank)
◼ Slide the slide lever on the toilet bowl in a clockwise direction. The slid-
ing trap is closed.
◼ Open the flap for the sewage tank on the outside of the vehicle. Insert
the key into the locking cylinder of the push-button lock (Fig. 148,1) and
turn a quarter turn in a clockwise direction.
◼ Remove the key.
◼ Press both push-button locks (Fig. 148,2) simultaneously with your
thumb and open the flap for the sewage tank.
Fig. 149 Sewage tank (in the vehicle)
Fig. 150 Sewage tank
◼ If the vehicle is equipped with an electrical ventilation system: Pull off
the hose of the ventilation system.
◼ Pull the safety clamp (Fig. 149,3) upwards and use the handle
(Fig. 149,2) to pull out the sewage tank (Fig. 149,1).
◼ At a disposal station that is especially provided for this purpose, swivel
the outlet pipe (Fig. 150,1) forwards and unscrew cover (Fig. 150,2).
◼ Press the coloured ventilation button (Fig. 150,3) and hold it there until
the sewage tank is empty.
◼ Clean the sewage tank with fresh water.
◼ Close outlet pipe with cover and swivel it back.
◼ Push sewage tank into the disposal chute until it engages.
◼ If the vehicle is equipped with an electrical ventilation system: Connect
the hose of the ventilation system.
◼ Close flap for sewage tank.
◼ Fill in new sanitary liquid.
