Electrical system 8
Exsis I/T - 01/23-1 - EHG-0027-02EN 115
80 Ah : 1.3 (gel battery) = 61.5 Ah
◼ Calculate the maximum operating time in accordance with the following
formula:
Max. effective energy [Ah] : Daily requirement [Ah] = Max. operating
time (in days)
61.5 Ah : 25.65 Ah = 2.39
The current battery capacity would be sufficient for more than two days if the
daily requirement remains the same.
The independent time period can be extended with use of the solar cells.
Two solar cells of 90 W produce the following gain:
◼ Summer: Approx. 60 Ah/day (independent operation reached)
◼ Winter: Approx. 15.5 Ah/day (in order to prolong independent operation,
another living area battery must be installed)
8.4.5 Retrofitting an AC converter
If an AC converter is retrofitted in the vehicle, this AC converter must be
designed for the specific conditions of the electrical system. Otherwise
the electrical system may be damaged. We will not be held liable for this
damage.
The retrofitting of an AC converter must only be carried out by author-
ised service centres.
The installation of a 230 V AC converter results in a very high current load.
For example an AC converter with a power output of 800 W on the 12 V side
has a current consumption of up to 75 A.
This current is much too big for the outputs on the transformer/rectifier (see
section 8.9.1).
If the AC converter is connected directly to the battery, the current consump-
tion of the AC converter will not be indicated by panel. Due to the high dis-
charging current, the terminal voltage in the battery drops significantly. The
measuring system installed then detects undervoltage and could switch off
the 12 V power supply. In addition the living area battery will be drained very
quickly if an AC converter is used.
Example:
Example:
Solar cells
