6 Living
92 B-MC I/T - 01/23-1 - EHG-0016-03EN
Fig. 82 Floor storage compartment
cover (handle recessed)
Fig. 83 Floor storage compartment
cover (handle swung out)
◼ If necessary, lay carpet segment aside.
◼ Push one side of the grip plate (Fig. 82,1) downwards. The handle
(Fig. 83,1) swivels upwards.
◼ Remove the cover (Fig. 83,2) upwards.
Close the lid and recess the handle as soon as possible. Otherwise,
there will be danger of tripping due to the open floor storage compart-
ment or the protruding handle.
Do not bend the carpet segments.
Do not leave the carpet segments laying in the room. Danger of trip-
ping!
◼ Insert the cover (Fig. 83,2) in the frame on the floor.
◼ Swivel handle downwards.
6.8 Multifunctional sideboard
Secure pull-out (Fig. 84,4) with lock (Fig. 84,5) against unintentional run-
ning in or out.
The maximum permitted pull-out (Fig. 84,4) load is 80 kg.
The vehicle can be equipped with a multifunctional sideboard instead of the
right-hand bench. Possible uses of the multifunctional sideboard:
⚫ Charging multimedia devices
⚫ Stowing objects, shoes, etc.
⚫ Footrest
⚫ Access assistance for the pull-down bed
⚫ Additional seat
Opening:
Closing:
