Living 6
B-MC I/T - 01/23-1 - EHG-0016-03EN 83
To bring the hinged roof window to the "continuous ventilation" position:
◼ Turn all catch levers (Fig. 68,3) a quarter turn towards the centre of the
window.
◼ Press the hinged roof window slightly outwards.
◼ Return all catch levers to their initial position. The locking catch
(Fig. 68,2) has to be moved into the recess of the window catch
(Fig. 68,1).
During the journey, the hinged roof window may not be in the "continuous
ventilation" position.
In the event of rain, splashing water can ingress into the living area if the
hinged roof window is in the "continuous ventilation" position. Therefore,
close the hinged roof window completely.
6.4.4 Roman shade and insect screen
The windows are fitted with a Roman shade and an insect screen. Roman
shade and insect screen are fixed to each other.
Fig. 69 Roman shade and insect
screen (hinged window)
The Roman shade is located in the upper window frame.
◼ Hold the Roman shade in the centre of the bottom rod (Fig. 69,2) and
carefully draw it downwards.
◼ Hold the bottom rod (Fig. 69,2) of the Roman shade in the centre and
carefully slide the Roman shade upwards.
The insect screen is located in the upper window frame.
◼ Pull insect screen at the handle (Fig. 69,1) downwards.
◼ Move the insect screen continuously.
If the insect screen is not drawn fully to the bottom, the Roman shade can
be stretched up to the end of the side window frame.
◼ Move insect screen at the handle (Fig. 69,1) fully upwards.
Roman shade
Closing:
Opening:
Insect screen
Closing:
Opening:
