4 During the journey

58 B-MC I/T - 01/23-1 - EHG-0016-03EN

4.17 Curtain shades for driver's window, windscreen, and

front passenger's window

 During the journey, the curtain shade must be open and secured.

◼ Push curtain shades back and secure them with straps and snap fasten-

ers.

4.18 Rear view camera / waste water tank camera

The vehicle is equipped with several cameras. Depending on the equipment,

the image of the cameras is fed into the multimedia/navigation system and

displayed on the existing display or on an external screen.

A camera module is installed in the upper part of the vehicle's rear.

1 Rear view mirror camera

2 Rear area lighting (LEDs)

3 Reversing camera

Fig. 35 Camera module

You can toggle between the following operating modes on the camera mo-

dule:

⚫ Reversing mode / monitoring mode: The reversing camera (Fig. 35,3)

shoots the immediate area behind the vehicle. The immediate area is

shown on the display. No camera image is displayed while travelling for-

ward.

⚫ Driving mode: The rear view mirror camera (Fig. 35,1) shoots the long-

distance area behind the vehicle. The long-distance area is shown on

the display ("3rd rear view mirror").

When going into reverse, the camera module automatically switches to re-

versing mode.

LEDs (Fig. 35,2) are integrated in the camera module. After dark, these

LEDs can illuminate the area behind the vehicle (when using the camera

and also independently of the camera).

A further camera (waste water tank camera) underneath the vehicle moni-

tors the area of the waste water tank outlet. This makes easier to mano-

euvre at a disposal station.

Securing:
