Electrical system 8
B-MC I/T - 01/23-1 - EHG-0016-03EN 135
95 Ah : 1.4 (lead battery) = 67.9 Ah
◼ Calculate the maximum operating time in accordance with the following
formula:
Max. effective energy [Ah] : Daily requirement [Ah] = Max. operating
time (in days)
67.9 Ah : 25.65 Ah = 2.65
The current battery capacity would be sufficient for more than two and a half
days if the daily requirement remains the same.
The independent time period can be extended with use of the solar cells.
Two solar cells of 90 W produce the following gain:
◼ Summer: Approx. 60 Ah/day (independent operation reached)
◼ Winter: Approx. 15.5 Ah/day (in order to prolong independent operation,
another living area battery must be installed)
8.4.5 Retrofitting an AC converter
Retrofitting of an AC converter can lead to damage to the electrical sys-
tem. We will not be held liable for this damage.
The installation of a 230 V AC converter results in a very high current load.
For example an AC converter with a power output of 800 W on the 12 V side
has a current consumption of up to 75 A.
This current is much too big for the outputs on the transformer/rectifier (see
section 8.15.1).
If the AC converter is connected directly to the battery, the current consump-
tion of the AC converter will not be indicated by panel. Due to the high
discharging current, the terminal voltage in the battery drops significantly.
The measuring system installed then detects undervoltage and could switch
off the 12 V power supply. In addition the living area battery will be drained
very quickly if an AC converter is used.
8.5 HYMER Smart Battery System
The HYMER Smart Battery System consists of one or more lead-fleece bat-
teries (hereinafter called lead batteries) and one or two HY-Tec lithium bat-
teries 135 (hereinafter called lithium batteries). Both are living area batteries.
Do not make any changes to the installation of the lithium battery carried
out at the factory.
Do not open the lithium battery.
Observe the recommended operating temperature between 15 and
25 °C. Take any further details on the operating temperature from the
manufacturer's instruction manual.
Fully charge the battery system every 6 months.
Switch the transformer/rectifier of for installation and maintenance.
Remove the fuses between lead-acid battery and lithium battery for in-
stallation and any work on the wiring.
Example:
Example:
Solar cells
