Living 6
B-MC I/T - 01/23-1 - EHG-0016-03EN 113
6.13.9 Conversion of divan and individual seat into additional bed
Do not place a load onto the converted table top until the cushions have
been laid correctly on the table top. Otherwise the table could be dama-
ged.
Together with the individual seat on the side and the lowered table top of the
suspension table, the divan can be converted into an additional bed. Two
additional cushions are needed to create the lying surface. An additional
board is also required, which is equipped with a fold-out support foot and a
support bracket.
Fig. 123 Prior to conversion
Fig. 124 After conversion
◼ Convert the suspension table into a bed foundation (see section 6.10.4).
◼ Remove seat cushion from individual seat.
Fig. 125 Additional board
◼ Unfold the support foot (Fig. 125,3) on the additional board (Fig. 125,1).
◼ Attach the support bracket (Fig. 125,2) of the additional board to the in-
dividual seat and place the additional cushion (Fig. 124,2) on the table
top.
◼ Place the second additional cushion (Fig. 124,1) on the table top.
◼ Attach the seat cushion of the individual seat again.
Setting up the additional
bed:
