2:2

OFF

ON

3 1 2

UNPACKING

1. Place the box on a steady, at surface. Lift off the

machine carrying case. Lift your machine out of the

box and remove the outer packaging.

2. Remove all other packing material and the plastic bag.

Note: Your DESIGNER RUBY Royale

™

sewing and embroidery

machine is adjusted to provide the best stitch result at normal room

temperature. Extreme hot and cold temperatures can affect the sewn

results.

CONNECT THE POWER CORD AND FOOT

CONTROL

Among the accessories you will nd the power cord and

the foot control.

Note: Before plugging in the foot control, check to ensure that it is type

“FR5” (see underside of foot control).

1. Pull out the cord from the foot control. Connect the

foot control cord to the front socket on the bottom

right side of the machine (1).

2. Connect the power cord to the rear socket on the

bottom right side of the machine (2).

3. Press the ON/OFF switch to “I” to turn on power

and light (3).

For the USA and Canada

This sewing machine has a polarized plug (one blade wider

than the other). To reduce the risk of electric shock, this

plug is intended to t in a polarized outlet only one way. If

the plug does not t fully in the outlet, reverse the plug. If

it still does not t, contact a qualied electrician to install

the proper outlet. Do not modify the plug in any way.

PACK AWAY AFTER SEWING

1. Press the ON/OFF (3) switch to “O”.

2. Unplug the cord from the wall socket and then from

the machine (2).

3. Unplug the foot control cord from the machine (1).

Pull the cord gently and release. The cord will retract

itself into the foot control.

4. Place all accessories in the accessory tray. Slide the tray

on to the machine, behind the free arm.

5. Place the foot control in the space above the free arm.

6. Place the hard cover over your machine.
