SELECTIVE THREAD CUTTER

Sewing Mode

Press the Selective Thread Cutter button and your machine

cuts the top and bobbin threads, raises the presser foot and

the needle, and activates the FIX function for the next start.

To cut threads at the end of a stitch or stitch program, press

Selective Thread Cutter while sewing. The button starts to

ash, indicating that a cut is requested. When the stitch or

stitch program is completed, the upper thread and bobbin

thread will be cut. The Selective Thread Cutter function can

be programmed, see Program chapter.

Note: Your machine cuts the threads automatically after certain

stitches such as completing a Sensor One Step Buttonhole. Automatic

Selective Thread Cutter can be cancelled in the SET Menu, see page

3:6.

Embroidery Stitch-Out

The Selective Thread Cutter automatically cuts the threads

and raises the presser foot. At the end of a color block the

top thread only is cut. When the design is nished, both

top and bobbin threads are cut automatically.

NEEDLE STOP UP/DOWN (TRIM POSITION)

Sewing Mode

Press the Needle Stop Up/Down to move the needle up or

down. The setting of the needle stop position is changed

at the same time. This function will also set the needle

position up or down when you stop sewing. You can also

tap the foot control to raise or lower needle once you stop

sewing.

Embroidery Stitch-Out

The machine will move the hoop forward, towards you, for

easy thread trimming.

SENSOR FOOT UP AND EXTRA LIFT

Sewing Mode

Press Sensor Foot Up to raise the presser foot. Press it a

second time and the presser foot will raise to Extra Lift,

and the feed teeth are lowered automatically to make it easy

to get thick fabric under the presser foot.

Embroidery Mode

Press the Sensor Foot Up and Extra Lift to lift the presser

foot to Up position. Press once more and the presser foot

will raise to Extra Lift, to make it easier to insert or remove

the hoop.

SENSOR FOOT DOWN AND PIVOT

The presser foot is lowered automatically when you start

sewing/embroidering.

Sewing Mode

Press the Sensor Foot Down and Pivot button and the

presser foot will be completely lowered. The machine

rmly holds the fabric. Press Sensor Foot Down again to

get the Pivot position.

Embroidery Mode

Press Sensor Foot Down to lower the presser foot into the

Embroidery “oat” position.

EXCLUSIVE SENSOR SYSTEM

™

Thanks to the EXCLUSIVE SENSOR SYSTEM

™

feature,

the presser foot continuously senses the thickness of fabric,

embroidery or stitching and sews over it smoothly and

evenly with perfect fabric feed.

Go to the SET Menu, Sewing Settings, to see the actual

setting of the Sensor presser foot pressure for the selected

fabric and adjust the presser foot pressure.

Needle Stop Up/Down

(Trim Position)

Speed - and +

STOP

(Monochrome)

FIX

(Baste)

Reverse

Start/Stop

Selective Thread Cutter

Sensor Foot Down and Pivot

Sensor Foot Up and Extra Lift
