3:2

Touch &

Hold

Sewing Mode Embroidery Mode

Ruby Menu

Quick

Help

Sewing/

Embroidery

Mode

Font Menu

Stitch Menu

Designs Menu

File Manager

TOOLBAR

On this toolbar you will nd the icons for the following

functions: Designs Menu, Stitch Menu, Font Menu, File

Manager, Ruby Menu, Quick Help and Sewing/Embroidery

Mode toggle.

SEWING/EMBROIDERY MODE

Toggle between the Sewing Mode and the Embroidery

Mode by touching the Sewing/Embroidery Mode icon.

Sewing Mode is used for ordinary sewing (see chaper 4 &

5) and Embroidery Mode for embroidering. When entering

Embroidery Mode, Embroidery Edit will be active. Here

you will be able to change the appearance of your design

(see chapter 7). To embroider your design, change from

Embroidery Edit to Embroidery Stitch-Out by touching

the GO! icon in the lower right corner of the Large

Interactive Screen (see chapter 8).

This section of the User’s Guide will guide you through the basic settings and functions of your machine. Learn how to navigate the functions

and settings on the Large Interactive Screen, and how to use the function buttons on the machine sewing head.

Detailed descriptions of the icons and functions found on the Large Interactive Screen in Sewing Mode, Embroidery Mode and File Manager

are described in separate chapters.

LARGE INTERACTIVE SCREEN

The screen is very easy to use - just touch it with your stylus to make your choices.

COMMON ICONS/FUNCTIONS

The following icons and functions on the screen are used frequently.

OK

Conrms settings or changes and returns to previous window.

CANCEL

Cancels settings and changes and returns to previous window.

TOUCH & HOLD

Some icons have additional functions, marked with an arrow at the lower right corner. To

access those functions, Touch & Hold the icon for a few seconds.
