16
Installation - NO Access Under
C. No Access Under Mounting Location
Use the following instructions to deck mount the Sensor and route the cable
to the side if there is not space for a cable underneath the mounting location.
NOTE
It is important to review the mounting considerations and test run the cable route
as indicated in Section 1 before proceeding with the installation.
1. Route the cable from the Sensor to the fish finder.
• The Sensor has two wire routing notches. Use the cable notch
closest to the intended cable route.
• If holes are required to route the cable, they must be 5/8" (15.9 mm)
to allow for the cable connector.
2. With the cable routed, position the Sensor in the planned mounting
location.
Position the sensor so the arrow on the cover is pointed straight toward
the front of the boat in the direction of travel. The arrow should be
parallel with the keel.
NOTE
Failure to align the sensor correctly will result in incorrect compass readings.
3. Make sure the Sensor is flush against the surface, and mark the two
mounting holes with a pencil or awl.
4. Move the Sensor to the side and drill the two 5/32" (4 mm) pilot holes.
NOTE
Apply marine-grade silicone caulk or sealant to both screw and drilled holes as
needed to protect your boat from water damage.
5. Align the Sensor’s screw holes over the pilot screw holes and attach
with the #8-19 x 1 1/2" Phillips head screws. Hand tighten only.
