10 Technical Data

GrandMeister 36 Head

Preamp tubes 3x 12AX7

Power tubes 4x EL84

Power output 36 watts

Max. power consumption 200 watts

Mains voltage tolerance range +/-10%

Ambient operating temperature range 0° to +35° C

Mains fuse, 100 volts 250 V / T 2 A L

Mains fuse, 120 volts 250 V / T 1.6 A L

Mains fuse, 220-230 volts 250 V / T 800 mA L

Mains fuse, 240 volts 250 V / T 800 mA L

Input jack 6.3 mm (1/4"), unbalanced, 1 MOhms

Sensitivity (Clean, without Boost, all Pots in

center position, Master in max. position)

-23 dbV

Max. Input (without Boost) 0 dbV

Return jack 6.3 mm (1/4"), unbalanced, 25 kOhms

Sensitivity (Clean, without Boost, all Pots in

center position)

0 dbV

Sensitivity (Clean, without Boost, all Pots in

center position, Master in max. position)

-10 dbV

Max. Input +14 dbV

Send jack 6.3 mm (1/4"), unbalanced, 220 Ohms

Nominal Level (Clean, without Boost, all

Pots in center position)

-10 dbV

Max. Level +10 dbV

Line Out jack 6.3 mm (1/4"), unbalanced, 220 Ohms

Nominal Level (Clean, without Boost, all

Pots in center position)

-10 dbV

Max. Level +10 dbV

Red Box Out XLR, balanced, 1360 Ohm

Nominal Level -10 dbV (at 3 watts output)

Max. Level +3 dbV

MIDI In 7-pin, 20 V DC phantom power (150mA),

5-pin compatible

MIDI Out/Thru 5-pin

Dimensions 446 x 171 x 152 mm

Weight 7,7 kg / 17 lbs.
