No. Component Description Source
D SUN2000 Select a proper model as
required.
Purchased from
the Company
E SmartLogger Select a proper model as
required.
Purchased from
the Company
F
Power meter
[1]
Recommended models:
DTSU666-H and DTSU666-HW
Purchased from
the Company
G Rapid shutdown
switch
Select a proper model as
required.
Prepared by the
customer
H Power grid
scheduling device
Select the devices that meet the
power grid scheduling
requirements.
Provided by the
local power grid
company
I
Smart Dongle
[2]
Supported models:
● WLAN-FE Smart Dongle:
SDongleA-05
● 4G Smart Dongle:
SDongleA-03, SDongleB-06
Purchased from
the Company
Note [1]: For details about meter operations, see DTSU666-HW Smart Power
Sensor Quick Guide and DTSU666-H 100 A and 250 A Smart Power Sensor
User Manual.
Note [2]: For details about how to use the WLAN-FE Smart Dongle
SDongleA-05, see
SDongleA-05 Quick Guide (WLAN-FE)
. For details about how
to use the 4G Smart Dongle SDongleA-03, see
SDongleA-03 Quick Guide (4G)
.
For details about how to use the Smart Dongle SDongleB-06, see
SDongleB-06
Quick Guide (4G)
. You can obtain the quick guides at https://
support.huawei.com/enterprise by searching for the Smart Dongle model.
Table 5-2 Cable description
No.
Name Type Conductor Cross-
Sectional Area
Outer
Diameter
1 PE cable Single-core
outdoor
copper cable
12KTL: ≥ 6 mm
2
15KTL–25KTL: ≥ 10
mm
2
-
2 AC output
power cable
Outdoor
copper cable
12KTL: 6–16 mm
2
15KTL–25KTL: 10–16
mm
2
11–26 mm
3 DC input power
cable
Common
outdoor PV
cable
4–6 mm
2
5.5–9 mm
SUN2000-(12KTL-25KTL)-M5 Series
User Manual 5 Electrical Connections
Issue 01 (2022-06-15) Copyright © Huawei Digital Power Technologies Co., Ltd. 27
