DEHUMIDIFY mode. The unit can evaporate the condensate water automatically by the
splash motor. Make sure the drainage holes are stemmed well.
- If water splash motor is damaged, continuous drainage can be used. To connect the drain
hose to the bottom drain hole (Fig.6), the unit can also work well.
- If splash motor is damaged, intermittent drainage can also be used. Under this condition, when
the water full indicator lights up, please connect a drain hose to the bottom drainage hole, then
all the water in the water tank will be drained outside. The unit can also work well.
7.InstallationExplanations
1. Installation Explanations:
- A removal air-conditioner shall be installed in the flat and empty place all around. Don’t block
the air outlet, and the required distance around should be at least 30cm. (See Fig.3)
- Should not be installed in wet location, such as the laundry room.
- Socket wiring should be in accordance with the local electric safety requirements.
Fig.3
2. Introduction to Exhaust Hose Installation
A) Temporary installation
1. Twist the housing Connector and the window Connector to the ends of the exhaust hose.
2. Insert the fixing clip of the housing adaptor into the openings at back of the air conditioner.
3. Put the other end of the exhaust hose to the near windowsill (see Fig.4).
7. Installation Explanations
44
