Table 2-4 Rear components and their descriptions (continued)
Component Description
(11) USB Type-C Thunderbolt port
1 (upstream)
Connects a Thunderbolt or USB Type-C DisplayPort cable to a source device such
as a computer or game console. This Thunderbolt port can function as a DisplayPort
input or as a USB 3.0 connection. It can also be used to deliver up to 100 W of power
to a device. Power outputs are 20 V/3.25 A, 15 V/4.33 A, 12 V/5 A, 9 V/3 A, or 5 V/3 A to
achieve a minimum 65 W output.
This port also enables the USB Type-A ports to perform their functions.
(12) RJ-45 (network) jack Network (RJ-45) data rate via USB Type-C max speed is 1000 Mbps
● Green (left): The network is connected.
● Amber (right): Activity is occurring on the network.
NOTE: Supports IT Manageability, out-of-band Wake on Lan (WOL) , out-of-band Mac
Address Passthrough (MAPT), and PXE boot (HP models only). The functionality may
vary with PC settings.
NOTE: This network port is fully energy efficient according to IEEE standards (IEEE
802.3az-2010) as long as all connected devices support this feature.
(13) USB Type-A ports (3) Connect a USB cable to a peripheral device, such as a keyboard, mouse, or USB hard
drive.
NOTE: This port also serves as the dedicated port for the Text-to-Speech (TTS)
adapter (the first USB Type-A port from left to right).
(14) USB Type-A port (BC 1.2)
(downstream)
Connects a USB cable to a peripheral device, such as a keyboard, mouse, or USB
hard drive.
Locating the serial number and product number
Depending on the product, the serial number and product number are located on a label on the rear of
the monitor or on a label under the front bezel of the monitor head. You might need these numbers when
you contact HP for support.
8
Chapter 2 Getting started
