Remove the access panel:
1. Loosen the captive screw (1) on the rear of the computer.
2. Slide the access panel (2) back, and then lift it (3) off the computer.
To install the access panel, reverse the removal procedure.
Optical drive
The optical drive is located in the drive cage. You can remove the optical drive without removing the front
bezel or the drive cage. To remove the optical drive, use these procedures.
Table 4-1
Optical drive descriptions and part numbers
Description Spare part number
DVD-ROM 932497-001
DVD-RW M75172-001
Optical drive latch M52203-001
Optical drive bezel P24512-001
Optical drive blank (for use in models without an optical drive) P24511-001
Before removing the optical drive, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 19).
2. Remove the access panel (see Access panel on page 19).
Remove the optical drive:
20
Chapter 4 Removal and replacement procedures
