● Industry-standard 288-pin
● 1.1 volt DDR5-SDRAM memory modules
● DDR5-5600 SDRAM UDIMM
● Mandatory JEDEC SPD information
The computer supports the following setups:
● 512 Mbit, 1 Gbit, 2 Gbit, and 4 Gbit non-ECC memory technologies
● Single-sided and double-sided memory modules
● Memory modules constructed with ×8 and ×16 DDR devices; memory modules constructed with ×4
SDRAM are not supported
NOTE: Memory modules support data transfer rates up to 5600 MT/s. Actual data rate is determined
by system configuration.
NOTE: When more than one memory slot is populated, symmetric configurations are required for two
DIMMs per channel. A mix of different data transfer rates or memory rank mix within the same channel
is not allowed.
NOTE: The system does not operate properly if you install unsupported memory modules.
There are two memory sockets on the system board, with two sockets per channel. The sockets are
labeled DIMM1 and DIMM2.
IMPORTANT: You must disconnect the power cord and wait approximately 30 seconds for the power
to drain before adding or removing memory modules. Regardless of the power state, voltage is always
supplied to the memory modules as long as the computer is plugged into an active AC outlet. Adding or
removing memory modules while voltage is present can cause irreparable damage to the memory
modules or system board.
The memory module sockets have gold-plated metal contacts. When upgrading the memory, it is
important to use memory modules with gold-plated metal contacts to prevent corrosion, oxidation, or
both resulting from having incompatible metals in contact with each other.
Static electricity can damage the electronic components of the computer or optional cards. Before
beginning these procedures, be sure that you are discharged of static electricity by briefly touching a
grounded metal object. For more information, see Electrostatic discharge information on page 9.
When handling a memory module, be careful not to touch any of the contacts. Doing so can damage
the module.
Before replacing the memory modules, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 19).
2. Remove the access panel (see Access panel on page 19).
3. (UMA models only) Remove the fan duct (see Fan duct (UMA models only) on page 22).
Replace a memory module:
32
Chapter 4 Removal and replacement procedures
