Daily Reference Guide

DELAY - The start of the program may be delayed for a period of time

between 0:30 and 24 hours.

1. Select the program and any desired options. Press the DELAY button

(repeatedly) to delay the start of the program. Adjustable from 0:30 to 24

hours. Once the 24 hours setting is reached, press the DELAY another time

to deactivate the DELAY function.

2. Press the START/Pause button and close the door within 4 sec. the timer

will begin counting down.

3. Once this time has elapsed, the indicator light switches o and the program

begins automatically.

The DELAY function cannot be set once a program has been started.

FAVOURITE PROGRAM  The FAVOURITE program may be saved and

will be easily accessible. Find the program using PREVIOUS/NEXT, and

then press the FAVOURITE program button for 3 seconds.

WATER TAP CLOSED – Alarm - Flashes when there is no inlet water or

water tap is closed.

LIGHT ON THE FLOOR - A LED light projected on the oor indicates

that the dishwasher is working. The light goes o at the end of a cycle.

This feature is active by default, but it is possible to deactivate it in the

“SETTINGS MENU”.

ActiveDry - It is a convection drying system which automatically opens

the door during/after the drying phase to ensure exceptional drying per-

formance every day. The door opens at a temperature that is safe to your

kitchen furniture.

As additional steam protection, specially designed protection foil is added

together with the dishwasher.

To see how to mount protection foil please refer to INSTALLATION GUIDE.

This feature is active by default, but it is possible to deactivate it in the

“SETTINGS MENU”.

SENSING - When the sensor is detecting the soil level an anima-

tion appears in the display (around 20 min.) and the cycle duration

is updated. SENSING is for the level of soiling on the dishes and

it is present for all cycles (excepting Eco) adjusting the program accordingly.

PROGRAMS TABLE

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories:

For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@europeanappliances.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Door is opened before the programm has been ended. This is to improve the drying eciency. Wait until the time has reached 00:00 to unload the dishwasher

**) Not all options can be used simultaneously.

***) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration by up to 20 min.

OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator

lights up) (see CONTROL PANEL). If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED ashes rap-

idly 3 times and beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.

OPTIONS AND FUNCTIONS

Program Programs description

Drying phase

ActiveDry

Available options

**)

Duration

of wash

program

(h:min)

***)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Program is suitable to clean normally soiled tableware, that

for this use, it is the most ecient program in terms of its combined

energy and water consumption, and that it is used to assess compli-

ance with the EU Ecodesign legislation.

4:30 9.9 0.55

Auto Intensive 65° - Automatic program for

heavily soiled dishes and pans.

Senses the level of soil-

ing on the dishes and

adjusts the program

accordingly. When the

sensor is detecting the

soil level an animation

appears in the display

and the cycle duration

is updated.

2:25-3:10 17.0-25.0 1.30-1.70

Auto Mixed 55° - Automatic program for nor-

mally soiled dishes with dried food residues.

1:20-3:20 7.5-20.5 0.75-1.20

Auto Fast Wash 50° - Automatic program for

normally and lightly soiled dishes. The every-

day cycle that ensures optimal cleaning and

drying performance in a shorter time.

1:00-1:50 8.0-16.0 0.70-1.10

Rapid 45° - Program is recommended for limited amount of lightly-soiled

dishes with no dried food residues. Does not include the drying phase.

0:30-0:40 10.5-15.0 0.55-0.65

Delicates 45° - Program for delicate items, which are more sensitive to

high temperatures, for example, glasses and cups.

1:40-1:50 12.5-17.0 0.95-1.20

Good Night 55° - Suitable for night-time operation of the appliance.

Ensures optimal cleaning and drying performance with the lowest noise

emission.

3:50-4:10 10.5-14.5 0.80-1.15

Sanitizing 65° - Normally or heavily soiled crockery, with additional anti-

bacterial wash. Can be used to perform maintenance of the dishwasher.

1:55-2:10 12.0-19.0 1.40-1.80

Soak - Used to refresh crockery planned to be washed later. Nodeter-

gent is to be used with this program.

0:12 4.5 0.10

P10

Self Clean 65° -

Program to be used to perform maintenance of the

dishwasher, to be carried out only when the dishwasher is EMPTY using

specic detergents designed for dishwasher maintenance.

1:15 12.7 1.10

EXTRA DRY - The higher temperature during the final rinse and the

extended drying phase allow improved drying. The EXTRA DRY option

results in the lengthening of the wash cycle.

HALF LOAD - If there are not many dishes to be washed, HALF LOAD is

used to save water, electricity or time, depending on the selected

program. Remember to halve the amount of detergent.

3D ZONE WAS

H - Thanks to the additional power jets this option provides

up to 80% more water power, a more intensive and powerful wash in the

lower rack, in the specic bottom area. This option is recommended for

washing pots and casseroles (please refer to the 3D loading section).
