Panel
4
Panel
1
2 2
3 4 5
6
7
8
9
10
1. Display Screen: Displays Ampero Mini’s current status. Use the touchscreen
to select effects, edit patches, and make tone adjustments.
2. Footswitch: Use to change patches, turn on/off effects, set tap tempo, etc
3. EXP/CTRL (FS 3/4): 1/4" TRS input, for connecting an external expression
pedal/footswitch controller. Perfect for Hotone Ampero Press or Ampero
Switch.
4. INPUT: 1/4" Mono input connection for both electric/acoustic instruments.
5. OUTPUT: Unbalanced 1/4" TRS stereo output connection to amplifiers or other
equipment. For stereo connection, a Y cable is needed to split L/R output
channels (Tip=Left channel, Ring=Right channel).
Left channel
Right channel
Blue stands for left channel (tip),
and red stands for right channel (ring)
6. PHONES: 1/8" stereo output for connecting headphones.
7. AUX IN: 1/8" stereo input for connecting external devices (phone, MP3 player)
for practice and jamming.
8. Volume Knob: Adjusts the overall volume of all output connections.
9. USB: USB 2.0 Type-C jack for connecting to your computer.
10. Power Supply Connection: Plug in the attached power supply (9V DC center
negative) to turn the unit on.
