FX LOOP

The FX LOOP module sends signal from previous slot/node to FX Loop Send jack and signal from the FX Loop Return jack to next

slot/node. When using with external devices, this module will “insert” the external device connected to FX Loop jacks to an

effects chain:

Signal from previous slot/node

External device

To next slot/node

From FX Loop Return jack

To FX Loop Send jack

Mixes internal/

external signal

FX LOOP

Available parameters are shown below:

Use Type to select input signal processing type:

•Mono (L): Mono I/O configuration, receives left channel of input signal only

•Mono (R): Mono I/O configuration, receives right channel of input signal only

•Stereo: Stereo I/O configuration

Use Send Level to adjust output level to FX Loop Send jack from Mute~-60dB~+20dB, default is set to 0dB.

Use Return Level to adjust input level from FX Loop Return jack from Mute~-60dB~+20dB, default is set to 0dB.

Use Mix to adjust signal ratio between signal from previous slot/node and signal FX Loop Return jack. The range is 0~100,

default is set to 50.

When set Mix to 0, only signal from previous slot/node will be sent.

When set Mix to 100, only signal from FX Loop Return jack will be sent.

Serial And Parallel FX Loop

•A Serial FX Loop means external device is connected to other effects chain in series:

•A Parallel FX Loop means external device is connected to other effects chain in parallel:

Signal from previous slot/node

External device

To next slot/node

From FX Loop Return jack

To FX Loop Send jack

FX LOOP

Signal from previous slot/node

External device

To next slot/node

From FX Loop Return jack

To FX Loop Send jack

FX LOOP

Ampero II Stomp supports both serial and parallel FX loop connection. Fine tune the parameters depending on your needs:

- Use as a serial FX loop

FX SND: Set Thru Level to 0

FX RTN and FX LOOP: Set Mix to 100, and Send Level cannot be muted

- Use as a serial FX loop

Set the parameter values differ from mentioned above; we recommend to keep default settings

Customizing Your Ampero II Stomp

DESIG N IN SPIRATIO N

Reminder: When using FX SND/RTN/LOOP modules, please be careful to prevent from abnormal operations (putting FX RTN

module before FX SND module, use more than two FX LOOP modules in an effects chain, using FX SND/RTN/LOOP modules

while setting input/output node source to FX Loop jacks, etc. ) which may cause abnormal noise, even unit malfunction.
