Available parameters are shown below:

Use Type to select input signal processing type:

•Mono (L): Mono I/O configuration, receives left channel of input signal only

•Mono (R): Mono I/O configuration, receives right channel of input signal only

•Stereo: Stereo I/O configuration

Use Send Level to adjust output level to FX Loop Send jack from Mute~-60dB~+20dB, default is set to 0dB.

Use Thru Level to adjust output level to next slot/node from Mute~-60dB~+20dB, default is set to 0dB.

Using FX Loop

To use unit’s FX loop jacks you need to:

(1) Assign input source/output destination to FX loop jacks (see Input Node Settings section on , Output Node Settings page 13

section on and USB Audio section on ) page 14 page 31

(2) Add a FX loop related module (FX SND/RTN/LOOP)

Next we’ll show you how to setup an FX loop related module.

FX SND (FX Loop Send)

The FX SND module will send the received signal from previous slot/node to FX Loop Send jack:

Signal from previous slot/node

FX SND

To next slot/node depending on

FX SND module settings

To FX Loop Send jack

Signal from previous slot/node

depending on module settings

FX RTN adjusts

signal ratio

To next slot/node

Signal from FX Loop Return jack

Available parameters are shown below:

Use Type to select input signal processing type:

•Mono (L): Mono I/O configuration, receives left channel of input signal only

•Mono (R): Mono I/O configuration, receives right channel of input signal only

•Stereo: Stereo I/O configuration

Use Return Level to adjust input level from FX Loop Return jack from Mute~-60dB~+20dB, default is set to 0dB.

Use Mix to adjust signal ratio between signal from previous slot/node and signal FX Loop Return jack. The range is 0~100,

default is set to 50.

When set Mix to 0, only signal from previous slot/node will be sent.

When set Mix to 100, only signal from FX Loop Return jack will be sent (this also means all slots/nodes before FX RTN jack will

be disabled).

FX RTN (FX Loop Return)

The FX RTN module will send the received signal from FX Loop Return to next slot/node:

Customizing Your Ampero II Stomp
