2. Cabinet Temperature Control and Display

The cabinet temperature is controlled by the cabinet control module and cabinet fan

motor(s) in conjunction with the rail control dial, rail control module, and cabinet fan relay.

The cabinet control module energizes the cabinet fan motor(s) when needed.

Note: The cabinet control module does not energize or de-energize the compressor.

WARNING! Adjusting the cabinet temperature setpoint only affects cabinet fan

motor operation. It does not control compressor operation. The cabinet fan motor

draws its cooling air from the rail area when the rail area is calling for cooling and the

compressor is energized.

a) Cabinet Temperature Setpoint Adjustment: The cabinet temperature is displayed

on the control module. To change the cabinet temperature setpoint, press the up

arrow and release. See Fig. 46. SP1 and the cabinet setting ashes. Press the up or

down arrow button to the desired temperature setpoint. 5-sec. later, the temperature

setpoint is saved and the display returns to normal display. NOTICE! Do not adjust

the temperature setpoint more than 2°F (1°C) at a time. Allow the temperature to

stabilize for a minimum of 8 hours before making further temperature setpoint

adjustments.

Factory Default: 35°F (1.7°C)

b) Cabinet Temperature Display Scale (°F or °C):

There are 4 temperature display settings from which to choose.

The factory temperature display default is F0 for °F whole number.

For a whole number temperature display scale value, select F0 or C0.

For a temperature display scale value to one decimal point, select F1 or C1.

Display Scale Temperature Display Style

F0 - Factory Default

35°F

2°C

35.0°F

1. 7 °C

To change the temperature display scale value, follow the steps below:

1) Press the "U" and "P" buttons together for 5 seconds. i.uP is displayed.

2) Press the "P" button. The current display setting (F0, F1, C0, or C1) and I.uP start

ashing.

3) Press the up or down button until the desired temperature display style is displayed.
