30
Fig. 19
5) After 10 minutes of operation, conrm bin control operation. Remove the front panel,
then press and hold the bin control's actuator paddle. The compressor and fan motor
should de-energize within 15seconds, then the drain valve should energize until the
water tank empties. After the water tank empties, the pump motor and drain valve
should de-energize.
6) Move the control switch to the "OFF" position, then turn off the power supply.
7) Remove the insulation panel, front frame, and splash curtain.
8) Finish draining the water tank by disconnecting the pump suction hose at the evaporator
case wall.
9) Disconnect the drain pipe and oat connection hose at the evaporator case wall.
Disconnect the water tank drain hose from the bottom of the water tank.
10) Remove the water tank.
11) Clean the dispenser unit/storage bin liner and water tank using a neutral cleaner. Rinse
thoroughly after cleaning.
12) Replace the water tank in the icemaker, then reconnect the hoses and drain pipe.
13) Replace the splash curtain, front frame, and insulation panel in their correct positions
and secure with the thumbscrews.
14) Seal the outer perimeter of the front frame to the icemaker and dispenser unit/storage
bin with RTV-748 sealant (provided) or equivalent. See Fig. 19. Make sure the front
frame sealant meets the previously applied perimeter sealant and that there are no
gaps.
Front Frame
Seal the Front Frame Outer Perimeter with RTV-748 Sealant
or Equivalent. Make sure the front frame sealant meets the
previously applied perimeter sealant and that there are no gaps.
15) Move the control switch to the "ON" position.
16) Replace the front panel in its correct position.
17) Turn on the power supply to start the automatic icemaking process.
18) Return to "II.H.2. Post-Startup" and complete nal checklist.
