41
13) Position and lock the ice chute onto the left and right brackets by pushing the ice chute
down until it clicks onto both brackets. See Fig. 46.
14) Slide in the water tank along the rails at the bottom of the left and right brackets until it
locks into place. See Fig. 47.
Right Bracket
Rail
Rail
Fig. 45
Fig. 46
Left Bracket
Ice Chute
Front Frame
Pipe
Rear Frame
Pipe
Water Tank
15) Reconnect the suction tube.
16) Hook each separator onto the rail, then pull it hard towards you until it locks into place.
See Fig. 47.
17) Replace the slope in its correct position. See Fig. 48.
Fig. 47
Fig. 48
Separator
Rail
Slope
18) Discard the sanitizing solution.
19) Mix a new batch of the sanitizing solution and slowly pour it into the water tank.
20) Move the control switch to the "WASH" position.
21) After circulating the sanitizing solution for 15 minutes, move the control switch to the "OFF"
position.
22) Disconnect the suction tube. Allow the water tank to drain, then reconnect the suction tube.
23) Repeat steps 19 through 22 one time.
24) Move the control switch to the "ICE" position and allow the appliance to operate for
2 minutes. This allows the water tank to ll with water.
25) Move the control switch to the "WASH" position.
26) Allow the water to circulate for 5 minutes, then move the control switch to the "OFF"
position.
27) Disconnect the suction tube. Allow the water tank to drain, then reconnect the suction tube.
28) Repeat steps 24 through 27 two more times to rinse thoroughly.
29) Clean the ice storage bin liner, door liner, and door gasket with a neutral cleaner. Rinse
thoroughly after cleaning.
30) Move the control switch to the "ICE" position to start the automatic icemaking process.
