11
Installer Setup Options (ISU)
ISU ISU Name ISU Options (factory default in bold)
1040
Scheduling Options (If you do not
wish to set a schedule, use the
default setting, then enter the
Schedule Menu after completing
setup and select Off)
1 = 1 week (all days the same)
2 = 5-2 Programmable (separate weekdays and weekend)
(The RTH20B only has the 5-2 day setting)
3 = 5-1-1 Programmable (separate Saturday and Sunday)
4 = 7-Day Programmable (each day separate)
1050 Temperature Indication Scale F = Fahrenheit C = Celsius (Default varies by model)
2000 Heating System Type
1 = Conventional Forced Air Heat
2 = Heat Pump
3 = Radiant Heat (Boiler)
5 = None (Cool Only)
If you are unsure what type of system you have, refer to your heating/cooling system equipment literature or call an HVAC
professional. If you select the wrong system type, the thermostat will not operate the equipment as intended.
2010 Heating Equipment Type
Conventional Forced Air Heat:
1 = Standard Efficiency Gas Forced
Air
2 = High Efficiency Gas Forced Air
3 = Oil Forced Air
4 = Electric Forced Air
5 = Hot Water Fan Coil
(ISU 2010 not shown when 2000
= Heat Pump)
Radiant Heat:
9 = Hot Water Radiant Heat
12 = Steam
2060 Reversing Valve O/B
0 = O (O/B on Cool. O wire is connected to the O/B terminal and
controls cooling.)
1=B (O/B on Heat. B wire is connected to the O/B terminal and
controls heat.)
The literature that came with your heat pump equipment should indicate
whether the reversing valve is energized in Heat or Cool mode
2070
Cool Stages/Compressor Stages
0, 1, 2 (1 if 2000 = 2)
Only 1 compressor stage available on RTH20B/RTHC20B and
RTH21B/RTHC21B. Select the number of Stages. For heat pumps,
only 1 stage is supported.
2071
Heat Stages/Backup Heat
Stages
Heat Stages: 1, 2
Backup Heat Stages: 0, 1 (RTH21B/RTHC21B and
RTH22B/RTHC22B)
2180
Aux Backup Heat Type (for Heat
Pump Systems)
31=Electric Forced Air (This thermostat only supports electric backup
heat. If your heat pump uses a gas or oil backup heat source, this
thermostat should not be used.)
3000 System Changeover
0 = Hidden (Manual only)
1 = Enabled
(Automatic available. In auto mode, the thermostat automatically
switches between heating and cooling to maintain the desired
indoor temperature. This option is not recommended if the outdoor
temperature often stays below 50F [10C] during winter months.)
Continued on the next page
Depending on system settings, not all options may be available
