ZUBEHÖR / ACCESSOIRIES
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at 25
SSAT1000_230V | SSAT2200_230V
SSAT2200_230V
No.
Description
Qty.
No.
Description
Qty.
No.
Description
Qty
1
Lock Nut ¼“
8
16
Filter Net
4
31
Motor Cord
1
2
Washer ¼“ × 25
8
17
Suction Board
11
32
Drawer
2
3 Motor
2×450
W / P2
18 Stopper 6 33 Pull Handle 2
4
Impeller
2
19
Rubber
198
34
Power Cord
1
5 Packing 8 20
Stopper Nut,
PG13.5
6 35
Phillips Head Screw,
3/16”x3/8”
1
6
Pin
8
21
Suction Head Set
1
36
Switch
2
7B
Flange Bolts, 5/16”-18 x
3/4”
20 22
Phillips Head
Screw, 3/16” x 3/8”
16 37 Nut 3/16” 1
8
Flat Head Screw, 1/4” x
5/8”
4 23 Right Side Cover 1 38 Tooth Washer, M4 1
9
Handle
2
24
Main Housing
1
39
Tapping Screw
4
10 Outlet Cover 2 26 Nut, 1/2” 6 40
Phillips Head Screw,
3/16” x 1/2”
4
11B
Flange Bolts, 5/16”-18 x
3/4”
12 27 Lock Nut, 1/2” 6 41 Switch Plate 1
12
Blower Housing
2
28
Pad
6
42
Switch Box
1
13 Hex Head Bolt, 1/4” x 1” 8 29
Cap Screw, 1/2” x
4”
6 43 Washer, 5/16” x 23 12
14
Left Side Cover
1
30
Bushing, MG-16
4
44
Lock Nut, 5/16”-18
12
15
Philips Head Screw, 1/4” x
3/8”
2
ZUBEHÖR / ACCESSOIRIES
(DE) Optionales Zubehör finden Sie online auf der Produktseite, Kategorie
EMPFOHLENES ZUBEHÖR ZUM PRODUKT.
(EN) Optional accessories can be found online on the product page, category RECOMMENDED
PRODUCT ACCESSORIES.
