ERSATZTEILE / SPARE PARTS
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at 24
SSAT1000_230V | SSAT2200_230V
19.2 Explosionszeichnung / Exploded view
SSAT1000_230V
No.
Description
Qty.
No.
Description
Qty.
No.
Description
Qty.
1 Lock Nut M6 3 14 Rubber 90 28
Tapping screw
ST3.5×20
4
2
Motor
1
15
Stopper nut
6
30
On/Off switch
1
3 Washer 3 16
Tapping screw
ST4.2×9.5
12 31 Bushing MG-16 3
4
Impeller
1
17
Suction head set
1
32
Power Cord
1
5
Packing
4
18
Screw M6×20
2
33
Pull Handle
1
6
Pin
6
19
Left side cover
1
34
Drawer
1
7
Screw M6×18
10
20
Hex Head Bolt
4
35
Screw M6×125
4
8
Screw M6×20
2
21B
Screw M6×20
4
36
Pad ø 60×25
4
9
Handle
1
22
Blower Housing
1
37
Washer 12
8
10
Outlet Cover
1
23
Switch Box
1
38
Lock Nut M12
4
11
Filter 395×495×25 mm
2
24
Screw M4x10
1
39
Lock Nut M12
4
12
Suction Board
5
25
Tooth washer 4 mm
1
40
Main Housing
1
13
Stopper
6
26
Switch Plate
1
41
Right side cover
1
27
Screw M5×12
4
43
Lock Nut M12×18
4
