ASSEMBLY
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at 21
SK90_230V
ASSEMBLY
14.1 Preparation
Check delivery content
Check the delivery immediately for transport damage and missing parts. Report any damage or
missing parts to your dealer or the shipping company immediately. Visible transport damage must
also be noted immediately on the delivery note in accordance with the provisions of the warranty,
otherwise the goods are deemed to have been properly accepted.
Requirements for the installation site
The selected installation site must ensure a suitable connection to the power supply and have a
connection to a compressed air supply. Observe the safety requirements and the dimensions of
the machine.
Place the machine on a level, solid surface that can support the weight of the machine. The chosen
installation site of the machine must comply with the local safety regulations as well as the
ergonomic requirements for a workplace with sufficient lighting conditions.
NOTE
The floor at the installation site must be able to bear the load of the machine!
When dimensioning the required space, take into account that the operation, maintenance and
repair of the machine must be possible without restrictions at all times.
Preparation of the surfaces
Before putting the machine into operation, carefully remove the corrosion protection or grease
residues from the bare metal parts. This can be done with the usual solvents. Under no
circumstances should you use nitro thinners or other cleaning agents, as these can attack the
machine´s finish.
NOTE
The use of paint thinners, petro, aggressive chemicals or scouring agents will damage
the surfaces!
Therefore: Use only mild cleaning agents!
14.2 Assemble
The machine has been disassembled for transport and must be reassembled before use. The
electrical connection and the pneumatic compressed air supply must be made. Follow the
instructions below (Numbering and lettering are identical to those in the delivery content and
exploded view):
1. Stick the sealing:
• Stick sealing (15) on the outer edge of front plate (D),
left plate(C) and right plate (E) as shown
NOTE: Ensure to stick sealing 10mm exceed for every
edge end
