ERSATZTEILE / SPARE PARTS
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at
29
MSM75_3IN1_230V | MSM75_3IN1_400V
No.
Description
Qty.
No.
Description
Qty.
1
Motor
1
52
Spring
1
2
Screw M6×12
8
53
Long lead Screw
1
3
Washer Ø6
8
54
Hex. Nut M16
3
4
Chip Box
2
55
Hand Wheel
1
5
Hex. Bolt M10×35
3
56
Bottom Fixed Pin
1
6
Washer Ø10
3
57
Washer Ø12
1
7
Support Plate
1
58
Spring Washer Ø12
1
8
Work Bench
1
59
Screw M12×25
1
9
Screw M10×30
1
60
Hex. Bolt M10×20
2
10
Spring Washer Ø10
1
61
Swing Nut
1
11
Stop Washer
1
62
Spring Washer Ø10
2
12
Motor Bracket
1
63
Cap Hex. Nut M12
1
13
Fixing Shaft
1
64
Large Washer Ø12
1
14
Washer Ø8
4
65
Washer Ø12
2
15
Spring Washer Ø8
4
66
Lifting Plate
1
16
Hex. Bolt M8×25
4
67
Screw M12×30
1
17
Large Washer Ø12
1
68
Hex. Bolt M12×20
1
18
Spring Washer Ø12
1
69
Spring Washer Ø12
1
19
Hex. Bolt M12×45
1
70
Washer Ø12
1
20
Set Screw M8×12
4
71
Belt Guide Shafting
1
21
Grinder Belt
1
72
Screw M10×20
1
22
Cabinet
1
73
Large Washer Ø10
1
23
Driving Wheel
1
74
Block
1
24
Pressure Plate
1
75
Tracking Knob
1
25
Spring Washer Ø8
1
76
Hex. Nut M10
1
26
Screw M8×25
1
77
Support Sleeve
1
27
Hinge Pad
2
78
Spring
1
28
Hex. Locking Nut M5
4
79
Thick Washer
1
29
Hinge
2
80
Hex. Locking Nut M8
1
30
Screw M5×16
8
81
Hex. Bolt M8×100
1
31
Hex. Thin Nut M10
2
82
Washer Ø8
1
32
Lock Block
1
83
Hex. Nut M8
1
33
Protective Cover
1
84
Locking Handle M10×30
2
34
Washer Ø10
1
85
Large Washer Ø10
2
35
Screw M10×20
1
86
Hex. Nut M10
2
36
Hex. Nut M4
8
87
Spring Plunger M10×20
2
37
Spring Washer Ø4
8
88
Support Body
1
38
Long Cover
1
89
Bearing 608
2
39
Screw M4×10
8
90
Roller
1
40
Lock Plate
2
91
Lifting Handle
1
41
Washer Ø4
4
92
Large Washer Ø8
1
42
Graphite Board
1
93
Hex. Bolt M8×30
2
43
Hex. Nut M4
4
94
Large Washer Ø8
2
44
Spring Washer Ø4
4
95
Short Sleeve
1
45
Washer Ø4
4
96
Long Sleeve
1
46
Screw M4×12
4
97
Feeding Handle
1
47
Guard
1
98
Handle Grip
1
48
Upper Fixed Pin
1
99
Hex. Bolt M8×16
4
49
Special Nut
2
100
Washer Ø8
4
50
Set Screw M5×6
2
101
Clamp. Ass.
1
51
Washer Ø16
3
