OPERATION
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at 48
ED750FDQ
Feed gear
Make sure that the oil level always reaches the mark of the
sight glass (1).
First oil change after 100 operating hours, then change the oil
once a year or after 1000 operating hours.
See Maintenance
Other oiling points
Lubrication points can be found on the drive shaft, on the lead screw, on the slides, on the
handwheels and on the tailstock. Lubricate these points regularly with a grease gun. See
Maintenance.
17.2.8 Function test
Check all spindles for ease of movement!
17.3 Electrical connection
W ARNI NG
Dangerous electrical voltage! Connection of the machine as well as electrical
inspections, maintenance and repair may only be carried out by qualified personnel
or under the supervision and supervision of a qualified electrician!
1. Check that the neutral connection and protective earthing are functioning properly
2. Check that the supply voltage and current frequency correspond to the specifications of
the machine
NO T IC E
Deviation of the supply voltage and current frequency
A deviation from the value of the supply voltage of ± 5% is permissible.
A short-circuit fuse must be provided in the power supply system of the machine!
3. Find the required cross-section of the supply cable (it is recommended to use a cable type
H07RN (WDE0282), taking measures to protect against mechanical damage) in a current
capacity data sheet.
4. Make sure that the power source is protected by a residual current circuit breaker.
5. Connect the unit only to a properly grounded outlet.
6. When using an extension cable, make sure that it is dimensioned appropriately for the
connected load of the machine (the connected load can be found in the technical data).
You can find the correlation between cable cross-section and cable length in specialist
literature or consult an electrician.
18 OPERATION
18.1 Operations preparation
Check Screw Connections
Check all bolted connections and tighten if necessary.
Check Oil Levels
Check the oil levels and top up with oil if necessary.
