– 4 –
Installation, Operation and Care Of
Model PW10n / PW20n / PW12n Prep Washer
SAVE THESE INSTRUCTIONS
GENERAL
ThePWnPrepWashersoccupyaminimumamountofoorspaceanddonotrequireseparate
dish tables. For all PW10n and PW20n models, the upper portion of the door raises, while
the lower portion swings out to provide a drain platform. The rack can then be pulled out for
easy loading and unloading. The PW12n models feature a single piece vertical lift door.
The unit can accommodate a 140-quart Hobart mixer bowl.
All PWn models are designed to operate in hot water sanitizing mode only; designated by
theNSFtemperaturerequirementsof150°Fwashand180°Fnalrinse.Thesetemperatures
can be found on the data label located under the controls on the lower part of the machine.
The HMI controls allow the operator to select a 2-, 4- or 6-minute cycle. The wash cycle is
followed by a dwell cycle and then a 10 second rinse. The PW10n-ADV, PW10n-ADVSW,
PW12n-ADV and PW12n-ADVSW Advansys models include a 70 second condensing
cycle following the rinse cycle and the PW20n-ADV Advansys model includes a 90 second
condensing cycle. The upper and lower wash arms provide thorough cleaning, and the upper
and lower rinse arms provide a sanitizing rinse at the end of each cycle. The PW10n-ADVSW
and PW12n-ADVSW models also include a side wash system.
All PWn models are only available with 16.4 kW electric tank heat and the built-in 16.4 kW
electric booster heater is standard on all models. The booster heater is designed to maintain
aminimumnalrinsetemperatureof180°Fprovidedtheincomingwatertemperatureis
110°F minimum. For ventless models PW10n-ADV, PW10n-ADVSW, PW20n-ADV, PW12n-
ADVandPW12n-ADVSW,theboosterheaterisdesignedtomaintainaminimumnalrinse
temperature of 180°F with cold incoming water of at least 55°F.
The wash pump motor on the PW10n and PW12n models is rated at 4 HP. The PW20n
models utilize two wash pump motors for a total of 8 HP.
Thelllineincorporatesanairgaponallmodelstopreventanybackowofwaterfromthe
prepwasherintothepotablewatersupply.Theunit,onceturnedon,llsthewashtanktothe
appropriatelevelandautomaticallystopsllingoncetheproperlevelisreached.Apressure
sensor reads the water level in the wash tank and shuts the heat off if the water level becomes
too low. When the water returns to the proper level, the heating circuit resumes operation.
The PW10n-BAS and PW20n-BAS models require a single hot water supply while the
PW10n-ADV, PW10n-ADVSW, PW20n-ADV, PW12n-ADV and PW12n-ADVSW models
require a hot water supply and a cold-water supply.
An automatic pumped drain and pumped rinse system are standard on all models.
Ventless models PW10n-ADV, PW10n-ADVSW, PW20n-ADV, PW12n-ADV and PW12n-
ADVSW do not require a vent hood. These models are equipped with an internal condensing
system to minimize the water vapor escaping from the unit. The PW10n-BAS and PW20n-
BAS models typically require a vent hood over the unit to meet local codes. Refer to pages
12-13 for venting and hood requirements.
The serial number can be found on the machine data plate located at the bottom right corner
of the upper door on PW10n and PW20n models and on the front right side of the machine
above the controls on PW12n models.
