– 13 –
Models PW10n-ADV, PW10n-ADVSW, PW20n-ADV, PW12n-ADV and PW12n-ADVSW do
not require a Type II vent hood. According to 507.3 of the 2021 IMC, Type II hoods are not
required where the heat and moisture loads are incorporated into the HVAC system design.
Refer to the below table for heat dissipation or heat gain to space machine data.
Vent Exit (Models PW10n-BAS / PW20n-BAS)
A vent exit (4-9/16 " x 17-3/8") is provided at the top of the machine to allow for expansion
of air. DO NOT directly connect the vent to an external vent.
Vent Fan Control (Standard); Power Vent Fan (Optional) (PW10n-BAS / PW20n-BAS)
The vent fan control feature is standard on all PW10n-BAS and PW20n-BAS models. This
feature is not available on the ventless models. The vent fan control relay provides switch
contacts only and does not provide power to the facility’s exhaust fan motor. The rating for
the vent fan control relay connected to terminals VFC1 and VFC2 is 1.5 amps at nameplate
supply voltage. When the machine is connected to the vent fan control circuit, the facility’s
exhaust fan is switched on when the machine is powered on and off when the machine is
powered off.
The Power Vent Fan accessory exhausts moist air from the chamber after the rinse cycle
is completed. The power vent fan may be selected to operate for 40, 60 or 80 seconds.
Thepowerventfankit(eldinstalledonly)extendsupward12-1/4”abovetheventexit
(13-5/16” above the top of the wash chamber) and terminates in a round duct connection
for a 10-1/4” O.D. duct.
Install power vent fan kit using a maximum of 60 ft of 10” diameter straight duct; or, 50 ft of
straight and two (2) 90°elbows, or equivalent. Distances greater than the stated maximum
lengthsmayreduceventingefciency.
NOTE: Refer to the Prep Washer Power Vent Fan Kit Installation Instructions (F-46049)
for more detailed information.
Model
Latent Heat
(BTU/HR)
Sensible Heat
(BTU/HR)
PW10n-BAS 12,300 5,300
PW10n-ADV, PW10n-ADVSW
PW12n-ADV, PW12n-ADVSW
9,900 6,300
PW20n-BAS 14,900 6,400
PW20n-ADV 14,200 8,700
PWn HEAT DISSIPATION
