– 23 –
MAINTENANCE
Maintenance and regular care is important to maintain optimal results with your Hobart warewasher.
Disconnect the electrical power to the machine (both dishwasher and booster if applicable)
and follow lockout / tagout procedures. Be sure all circuits are disconnected.
WASH ARMS
Upper and lower wash and rinse arms should turn freely and continue turning for a few seconds after being
rotated by hand. Remove any obstructions causing improper operation.
If either the strainer pan or the strainer basket is not properly in place, obstructions (such as food particles or
bones) may clog the wash arm nozzles. The wash arms are easily removed for cleaning.
To remove the lower wash arm on the LXnC and LXnH models, unscrew the thumb nut and lift the rinse arm
off (page 17, Fig. 6). The wash arm can be lifted off once the rinse arm is removed. The upper wash and
rinse arms are removed by unscrewing the thumb nut and lowering both arms together. Be careful not to drop
the arms.
To remove the lower wash arm on the LXnR, LXGnR and LXGnPR models, press in on the buttons located
on the sides of the center hub and lift the rinse arm off (page 17, Fig. 7). The wash arm can be lifted off once
the rinse arm is removed. The upper wash and rinse arms are removed by pressing in on the buttons located
on the sides of the center hub and lowering both arms together. Be careful not to drop the arms.
MOTORS
The wash pump motor, rinse pump motor, drain pump motor and fan motor (LXnR and LXGnR models only)
are equipped with permanently lubricated bearings and require no lubrication maintenance.
CHEMICAL PUMPS
Inspect chemical tubes every 3 months and replace as required. Also inspect chemical bottle caps and
standpipes to ensure they are not cracked or worn.
When using rinse aid, inspect the suction strainer located at the end of the chemical standpipe every
3 months to ensure it is not clogged.
DELIME INSTRUCTIONS
Deliming solution, rinse agents or any other kind of acid must not come in contact with
bleach or rinse solution containing bleach used in chemical-sanitizing machines. Mixing may cause
hazardous gas to form. This entire procedure must be followed step by step for safe and satisfactory
results.
Do not allow the deliming agent to remain in the machine longer than recommended by the deliming
agent manufacturer.
DELIME THE DISHWASHER ON A REGULAR BASIS AS REQUIRED. The regularity will depend on
mineral content of the supply water and machine usage. Deliming should be done when you can see clear
signs of lime deposits (a white, chalky substance) on the inside walls and on the wash arms. All LXn / LXGn
models are equipped with an automatic delime cycle reminder. It is recommended that deliming be done
when Delime Required. Start Delime Cycle? is lit. LXnR and LXGnR models are equipped with an internal
delime pump which will automatically pump the required amount of deliming agent into the unit.
If deliming is necessary, a deliming agent (such as Lime-A-Way
®
or LSR
®
) should be used for best results.
