– 15 –
EQUIPMENT CONNECTIONS
Electrical and grounding connections must comply with the applicable
portions of the National Electrical Code, NFPA 70 (latest edition) and / or other local
electrical codes.
Disconnect the electrical power to the machine (both dishwasher
and booster if applicable) and follow lockout / tagout procedures. Be sure all circuits
are disconnected.
Vent Fan Control
The vent fan control feature is standard on all non-ventless AM16 models. The vent fan
control relay provides switch contacts only and does not provide power to the vent fan
motor. The rating for the vent fan control relay connected to terminals VFC1 and VFC2 is
1.5 amps at nameplate supply voltage. When the dishwasher is connected to the vent fan,
the vent fan is switched on when the dishwasher is on and off when the dishwasher is off.
HOBART SUPPLIED DETERGENT, RINSE AID AND SANITIZER DISPENSER INSTALLATION
All AM16-SCB, AM16VL-SCB and AM16-SVLT models ship standard with chemical pumps.
Chemical pumps are available as an accessory kit for all other models. For standard height
machines, order sales accessory code CHEMPUMP-STD-AM16 or service part # 00-
563068-00002. For tall machines, order sales accessory code CHEMPUMP-HTS-AM16
or service part # 00-563069. For all machines equipped with the Hobart chemical pumps,
refer to 0F-45893 Installation Instructions shipped with the machine or in the accessory kit.
Chemical Pump Programming (For Machines Equipped with Hobart Chemical Pumps)
NOTE: The Chemical Dispensing Module is factory preset to the following settings. This
adjustment procedure is to verify or alter settings if chemical dosing changes are
required to achieve proper concentrations.
1. Power on dishwasher. Display shows ready screen when ll cycle has completed.
2. Press ‘Menu’ button.
3. With ‘Manager Menu’ highlighted, press the ‘Enter’ button. The ‘Enter PIN’ screen will
be displayed.
4. The default manager code is 1001. Use the arrow buttons to change the value and
then press the ‘Enter’ button to select the value and toggle to the next digit until the
code is entered.
5. After pressing ‘Enter’ for the last digit, use the down arrow and scroll until ‘chemical
menu’ is outlined. Press Enter.
6. Below is a list of the editable parameters and the Hobart factory settings for the built-in
Hobart chemical pumps. Use the Up and Down Arrows to toggle to the next Parameter.
a. To change a parameter value, press the Enter button once the parameter is outlined.
b. Press the Up and Down Arrows to change the parameter value.
c. Once the required parameter value is displayed, press the ‘Enter’ button to
save the selection.
7. To exit the programming, use the Up and Down Arrows to scroll thru the parameters until
‘back’ is outlined and press the ‘Enter’ button. Repeat this procedure until the Ready
screen is displayed.
