P O L A R 10/12 MK2 1.0
8
Delay
Establish Bluetooth connection (press
again to select between ON, OFF and
TWS. Selecting ON makes POLAR
visible to other Bluetooth devices).
BT ON/OFF
Adjust high frequency:
+/- 12 dB (default: 0 dB)
Hi EQ
Adjust mid frequency:
+/- 12 dB (default: 0 dB)
Mid EQ
Set mid frequency:
70 Hz – 12 kHz (default: 1 kHz)
Mid Freq
Adjust low frequency:
+/- 12 dB (default: 0 dB)
Low EQ
Music (default)
Voice
DJ
Mode
Load Preset
O: turns o delay function (default)
0–100 m: choose delay distance
Delay
O: display is constantly on (default)
On: after 8 sec. of no operation, display turns dark
LCD Dim
Load customized settings
Store Preset
Store customized settings
Erase Preset
Erase selected preset
Brightness
Display brightness 0 – 10 (default: 5)
Contrast
Display contrast 0 – 10 (default: 5)
Factory Reset
Reset all settings to default
Exit
Exit DSP menu
Use the "Delay" menu option if you need to delay the audio playback via the
POLAR speakers. The system makes it easy to do this: simply set the delay
from 0 (o) to 100meters in 0.25meter increments.
Good to know: The delay function comes very handy if you want to
use POLAR as a delay line for larger events. In acoustically challenging
venues, it can help you distribute sound more uniformly, improve speech
intelligibility all the way to the back rows, achieve high-quality audio,
and reduce the volume of the main PA up front by the stage. All you need
to do to sync POLAR up with the main PA is enter the distance between
POLAR and the stage in meters.
PH Power (phantom power)
Activating PH Power switches on a phantom voltage on CH 1 and CH 2.
Ph. ON appears on the display.
Phantom power is required, for example, to operate condenser micro
-
phones.
Ph.ON
3.3 Managing Presets
Establish Bluetooth connection (press
again to select between ON, OFF and
TWS. Selecting ON makes POLAR
visible to other Bluetooth devices).
BT ON/OFF
Adjust high frequency:
+/- 12 dB (default: 0 dB)
Hi EQ
Adjust mid frequency:
+/- 12 dB (default: 0 dB)
Mid EQ
Set mid frequency:
70 Hz – 12 kHz (default: 1 kHz)
Mid Freq
Adjust low frequency:
+/- 12 dB (default: 0 dB)
Low EQ
Music (default)
Voice
DJ
Mode
Load Preset
O: turns o delay function (default)
0–100 m: choose delay distance
Delay
O: display is constantly on (default)
On: after 8 sec. of no operation, display turns dark
LCD Dim
Load customized settings
Store Preset
Store customized settings
Erase Preset
Erase selected preset
Brightness
Display brightness 0 – 10 (default: 5)
Contrast
Display contrast 0 – 10 (default: 5)
Factory Reset
Reset all settings to default
Exit
Exit DSP menu
Load Preset
Five memory slots (U1 to U5) are available for storing your personal DSP
settings. "U" stands for user preset. A user preset contains the settings
for all parameters in the DSP menu (mode, three-band EQ, delay, display
brightness, etc.).
Turn the Master knob to select the preset you wish to load from U1 through
U5, and then press the knob to load the selected preset. "Exit" quits the
menu without loading a preset.
Store Preset
This option stores the current DSP menu settings. Turn the Master knob to
select the desired memory slot from U1 through U5. Confirm your selection
by pressing the Master knob. A box serving to name this preset appears in
the display. "Exit" quits the menu without saving a preset.
Text Editor: Turn the Master knob to access the text box and navigate the
menu to the “Save”, “Clear” and “Cancel” options. Once you have dialed up
the text box, press the knob to select the first of the twelve character spac
-
es, and then turn it to select a letter or character. Press the knob again to
move to the next character space, and then turn it to select the next letter
or character. Press the Master knob twice – without turning it – to exit the
text box. The enter symbol, an arrow, will appear in the display. Now you
can turn the knob to navigate from the text box to the “Save”, “Clear” and
“Cancel” options.
Save: Selecting “Save” lets you store the preset by pressing the Master
knob. This takes you back to the U1 to U5 selection menu, where you can
copy the preset to another memory slot or quit the menu via Exit.
Clear: Selecting “Clear” lets you wipe the Text box clean by pressing the
Master knob so you can enter a new name.
Cancel: Selecting “Cancel” lets you stop the naming process by pressing the
Master knob. This takes you back to the U1 to U5 selection menu, where
you can select a dierent memory slot or cancel the entire saving process
via “Exit”.
Erase Preset
This option serves to delete the selected preset. Pressing the Master knob
does not yet erase the preset. A confirmation prompt appears first:
Confirm Erase: Yes/No
Turn the knob to select “Yes” or “No”, and then press the Master knob to
confirm your selection. “Yes” irrevocably deletes the preset; “No” takes you
back to the DSP menu.
3.4 Display
Establish Bluetooth connection (press
again to select between ON, OFF and
TWS. Selecting ON makes POLAR
visible to other Bluetooth devices).
BT ON/OFF
Adjust high frequency:
+/- 12 dB (default: 0 dB)
Hi EQ
Adjust mid frequency:
+/- 12 dB (default: 0 dB)
Mid EQ
Set mid frequency:
70 Hz – 12 kHz (default: 1 kHz)
Mid Freq
Adjust low frequency:
+/- 12 dB (default: 0 dB)
Low EQ
Music (default)
Voice
DJ
Mode
Load Preset
O: turns o delay function (default)
0–100 m: choose delay distance
Delay
O: display is constantly on (default)
On: after 8 sec. of no operation, display turns dark
LCD Dim
Load customized settings
Store Preset
Store customized settings
Erase Preset
Erase selected preset
Brightness
Display brightness 0 – 10 (default: 5)
Contrast
Display contrast 0 – 10 (default: 5)
Factory Reset
Reset all settings to default
Exit
Exit DSP menu
LCD Dim: Deactivate (O) this function if you want the display to remain
bright. Activate it (On), and the display will dim eight seconds after you
last used the Master knob. The readout darkens, but it will remain clearly
legible. As soon as you use the Master knob, the display will brighten to the
set level.
Bright: Adjusts the display’s brightness from 0 to 10.
Contrast: Adjusts the display’s contrast from 0 to 10.
3.5 Factory Reset
Bluetooth-Verbindung herstellen (erneutes
Drücken lässt zwischen ON, OFF und TWS wählen.
Durch wählen von ON wird POLAR für andere
Bluetooth-Geräte sichtbar.)
BT ON/OFF
Höhen-Klangregelung:
+/- 12 dB (Voreinstellung: 0 dB)
Hi EQ
Mitten-Klangregelung:
+/- 12 dB (Voreinstellung: 0 dB)
Mid EQ
Mitten-Frequenz:
70 Hz – 12 kHz (Voreinstellung: 1 kHz)
Mid Freq
Bass-Klangregelung:
+/- 12 dB (Voreinstellung: 0 dB)
Low EQ
Music (Voreinstellung)
Voice
DJ
Mode
Load Preset
O: Delay-Funktion deaktiviert (Voreinstellung)
0–100 m: Delay-Distanz
Delay
O: Display leuchtet konstant (Voreinstellung)
On: Display dunkelt nach Bedienung ab
LCD Dim
Preset laden
Store Preset
Preset speichern
Erase Preset
Preset löschen
Brightness
Display-Helligkeit 0 – 10 (Voreinstellung: 5)
Contrast
Display-Kontrast 0 – 10 (Voreinstellung: 5)
Factory Reset
auf Werkseinstellungen zurücksetzen
Exit
DSP-Menü verlassen
Reset
• “Reset” lets you restore POLAR’s factory DSP settings.
• Pressing the Master knob does not yet trigger a reset. A security prompt
appears first:
Confirm Reset: Yes/No
Turn the knob to select “Yes” or “No”, and then press the Master knob to
confirm your selection. “No” takes you back to the DSP menu,“Yes” irrevoca
-
bly resets all DSP functions to the factory defaults, with “Music” mode acti-
vated, the Bluetooth connection severed, and all five user presets erased.
Good to know: This function comes in handy if you frequently rent the
system out. It lets you quickly restore the factory settings before hand
-
ing the system over to the next customer.
3.6 Exit DSP Menu
Establish Bluetooth connection (press
again to select between ON, OFF and
TWS. Selecting ON makes POLAR
visible to other Bluetooth devices).
BT ON/OFF
Adjust high frequency:
+/- 12 dB (default: 0 dB)
Hi EQ
Adjust mid frequency:
+/- 12 dB (default: 0 dB)
Mid EQ
Set mid frequency:
70 Hz – 12 kHz (default: 1 kHz)
Mid Freq
Adjust low frequency:
+/- 12 dB (default: 0 dB)
Low EQ
Music (default)
Voice
DJ
Mode
Load Preset
O: turns o delay function (default)
0–100 m: choose delay distance
Delay
O: display is constantly on (default)
On: after 8 sec. of no operation, display turns dark
LCD Dim
Load customized settings
Store Preset
Store customized settings
Erase Preset
Erase selected preset
Brightness
Display brightness 0 – 10 (default: 5)
Contrast
Display contrast 0 – 10 (default: 5)
Factory Reset
Reset all settings to default
Exit
Exit DSP menu
This menu option lets you quit the DSP menu and restore the Master knob
to its function as a volume control. This also happens automatically if you
leave the Master knob to idle for eight seconds.
